纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-005) - RADIATOR INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
468 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX05P00002F1 | [1] | RADIATOR | KOBINSTAL |
| A1. | YX05P01024P1 | [1] | STAY | KOBSTAY |
| A2. | ZS18C16035 | [3] | SCREW,Hex, M16 x 35mm | KOBCAP |
| A3. | ZW16H16000 | [3] | WASHER | KOB |
| A4. | 2420T6786 | [2] | BOLT,M12 x 1.75 x 25mm | KOBSEMS Superseded by part number: ZM32C12025 |
| . . | YV05P00006F1 | [1] | RADIATOR GROUP | |
| B1. | YV05P01020P1 | [1] | FLEXIBLE HOSE | KOBRADIATOR |
| B2. | YW05P01027P1 | [1] | FLEXIBLE HOSE | KOBRADIATOR |
| B3. | YY05P01010F1 | [1] | BRACKET | KOBASSY, Serial Range: YV04-03043-YV04-03293 Superseded by part number: YY05P01137F1 |
| . . | YY05P01137F1 | [1] | BRACKET | KOBASSY, Start Serial: YV04-03294 |
| B3-1. | YY05P01012P1 | [1] | BRACKET | KOB, Serial Range: YV04-03043-YV04-03293 Superseded by part number: YY05P01135P1 |
| . . | YY05P01135P1 | [1] | BRACKET | KOB, Start Serial: YV04-03294 |
| B3-2. | YX05P01019P1 | [1] | FOAM INSULATION | KOB |
| B3-3. | YY05P01011P1 | [1] | FOAM INSULATION | KOB |
| B3-4. | YX05P01034P1 | [1] | FOAM INSULATION | KOB |
| B3-6. | 2427P1836D41 | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| B3-7. | 2427P1836D17 | [1] | WEATHERSTRIP | KOB |
| B3-8. | 2427P1836D38 | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| B4. | YV05P01023P1 | [1] | GUARD | KOB |
| B5. | YX05P01012F1 | [1] | TANK | KOBASSY, WATER, SUB |
| B5-1. | YX05P01012S001 | [1] | TANK | KOBWATER Superseded by part number: YX05P01012F1 |
| B5-2. | YN05P01041S2 | [1] | CAP ASSY. | KOB Superseded by part number: YN05P01041S002 |
| B5-3. | 2427U203S3 | [1] | LABEL | KOB |
| B6. | YY05P01020P1 | [1] | BRACKET | KOB |
| B7. | HX11Y05064DX | [1] | HOSE,8mm ID x 640mm L | KOB |
| B8. | HX11Y05120DX | [1] | HOSE | KOB |
| B9. | YX05P01026P1 | [1] | FOAM INSULATION | KOB |
| B10. | YY05P01013P1 | [1] | FOAM INSULATION | KOB |
| B11. | YY05P01014P1 | [1] | FOAM INSULATION | KOB |
| B14. | YY05P01027D1 | [1] | HOSE | KOB |
| B15. | ZS18C08020 | [10] | SCREW,Hex, M8 x 20mm | KOB |
| B16. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOB |
| B17. | ZW16X08000 | [10] | WASHER | KOB |
| B18. | ZW16X10000 | [2] | WASHER | KOB |
| B19. | ZC16X01200 | [2] | CLIP,8mm - 15mm | KOBClamp, Hose -- Min 08 x Max 15mm |
| B20. | ZC16X05000 | [1] | CLIP | KOB |
| B21. | ZC16X05800 | [3] | CLIP | KOB |
| C1. | YV05P00005F1 | [1] | RADIATOR | KOBASSY (SEE FIG 01-006) |
