纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-006) - RADIATOR ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
671 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV05P00005F1 | [1] | RADIATOR | KOBASSY |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONCORE, RADIATOR |
| 2. | YT05P00001S002 | [1] | CAP | KOB |
| 3. | 2452U183S5 | [1] | PLUG | KOB |
| 5. | YY05P00004S005 | [1] | BRACKET | KOBASSY |
| 6. | YY05P00004S006 | [1] | BRACKET | KOBASSY |
| 7. | YW05P00009S010 | [18] | BOLT | KOBSEMS |
| 8. | YV05P00005S008 | [1] | SHROUD | KOB |
| 10. | YY05P00004S010 | [1] | OIL COOLER | KOB |
| 12. | YY05P00004S012 | [2] | PACKING | KOB |
| 13. | YV05P00005S013 | [1] | COVER | |
| 14. | YW05P00009S003 | [8] | BOLT | KOBSEMS |
| 15. | YY05P00004S015 | [2] | PACKING | KOB |
| 16. | YV05P00005S016 | [1] | COVER | |
| 19. | YY05P00004S019 | [1] | NET | KOBCATCH, INSECT |
| 20. | YY05P00004S020 | [1] | NET | KOBCATCH, INSECT |
| 21. | YY05P00004S021 | [1] | BRACKET | KOBASSY |
| 23. | 2452U202S5 | [6] | BOLT | KOBWING |
| 24. | 2452U412S20 | [6] | WASHER | KOB |
| 25. | YY05P00004S025 | [1] | BRACKET | KOBASSY |
| 26. | YY05P00004S026 | [1] | BRACKET | KOBASSY |
| . . | YV05P00005R100 | [1] | RADIATOR | KOBSERVICE KIT, CONSISTS OF REF 1, 2, 3 |
