纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-014) - TANK ASSY, FUEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
163 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY20P00013F1 | [1] | TANK ASSY, FUEL | |
| A1. | YY20P00012P1 | [1] | FUEL TANK | KOB |
| A2. | YY50V00001P1 | [1] | STRAINER ASSY. | KOB |
| A3. | YN20P01034P2 | [1] | CAP | KOBFILLER |
| A4. | YX20P01020P1 | [1] | FLANGE | KOBCOVER |
| A5. | ZD11P13000 | [1] | O-RING | KOB |
| A6. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOB |
| A7. | ZW16X10000 | [4] | WASHER | KOB |
| . . | YY20P00007F2 | [1] | TANK INSTAL, FUEL | |
| B1. | ZS18C16040 | [4] | SCREW,Hex, M16 x 40mm | KOBCAP |
| B2. | ZW16H16000 | [4] | WASHER | KOB |
| B3. | YN52S00034F1 | [1] | SENSOR | KOBASSY, LEVEL |
| B4. | 2418T9962 | [1] | PACKING | KOB |
| B5. | ZS31C05012 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBMACHINE |
| B6. | ZW26X05000 | [5] | LOCK WASHER | KOBLOCK |
| B8. | 2436R339 | [1] | COCK, DRAIN | KOB |
| B9. | YN22C01099D9 | [2] | WEATHERSTRIP | KOB |
| B10. | YX20P01005P1 | [1] | PLATE | KOB |
| B11. | ZM32C12030 | [1] | BOLT | KOBSEMS |
| B13. | YY20P01028P1 | [1] | INDICATOR | KOBINSULATION |
| B14. | ZS18C12040 | [1] | SCREW,Hex, M12 x 40mm | KOBCAP |
| B15. | ZW26X12000 | [1] | WASHER | KOB |
| B16. | 2418T10357 | [1] | WASHER | KOB Superseded by part number: 2418T12345 |
| B17. | LE33H01017D1 | [1] | SHIM | KOB(1.0) |
| B18. | LE33H01017D2 | [1] | SHIM | KOB(0.5) |
| B19. | YY20P01026D1 | [1] | INDICATOR | KOB |
| B20. | YY20P01027D1 | [1] | INDICATOR | KOB |
| B21. | YN21C01528D8 | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| B22. | YJ21C01154D4 | [1] | RUBBER | KOB |
| B23. | YY20P01079P1 | [1] | INSULATING PANEL | KOB |
| B24. | YY20P01080P1 | [1] | INSULATING PANEL | KOB |
