纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-017) - POWER TAKE-OFF ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
881 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YY10V00001F4 | [1] | PUMP | KOBASSY, HYD, Serial Range: YV04-03043-YV04-03269 Superseded by part number: YY10V00001F6 |
| 0. | YY10V00001F5 | [1] | PUMP | KOBASSY, HYD, Serial Range: YV04-03270-YV04-03403 Superseded by part number: YY10V00001F6 |
| 0. | YY10V00001F6 | [1] | HYDRAULIC PUMP | KOBASSY, Start Serial: YV04-03404 |
| . . | YX30P00002F1 | [1] | POWER TAKE-OFF ASSY | |
| 1. | YX30P01001P1 | [1] | BRACKET | KOB |
| 2. | 2418U224F2 | [1] | COUPLING | KOBASSY |
| 2-2. | 2418U224S2 | [1] | HUB | KOB |
| 2-3. | 2418U162S2 | [4] | BOLT | KOB |
| 2-4. | 2418U128S5 | [4] | SCREW | KOBCAP |
| 2-5. | 2418U162S3 | [2] | SCREW | KOBSET |
| 2-6. | ZP26D05010 | [8] | PIN | KOBSPRING |
| 2-7. | 2418U224S7 | [1] | RUBBER INSULATOR | KOBPAD |
| 3. | ZS18C10028 | [11] | CAPSCREW,Hex, M10 x 28mm | KOBSCREW CAP Superseded by part number: ZS18C10030 |
| 4. | ZS23C16045 | [4] | CAP,Hex Socket Head, M16 x 45mm | KOBSCREW |
