| 1. |
84819669
|
[2] |
DUST CAP
|
ZED
|
| 2. |
84819661
|
[2] |
QUICK MALE COUPLING
|
ZED
|
| 3. |
87492507
|
[2] |
FLEXIBLE HOSE,7.92mm ID x 2500mm L, SAE 100R1
|
ZED
|
| 4. |
150017
|
[4] |
HYD CONNECTOR,M16 x 1.5 x M16 x 1.5
|
ZED
Superseded by part number: 47499003
|
| 5. |
84432924
|
[1] |
HYD TUBE,10 mm OD
|
ZED
, Serial Range: -C719
|
| 5. |
84163012
|
[1] |
HYD TUBE,10 mm OD
|
ZED
, Start Serial: D720
|
| 5. |
84007696
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C719
|
| 5. |
84163008
|
[1] |
HYD TUBE,10 mm OD x 2155, 489 mm L
|
ZED
, Start Serial: D720
|
| 6. |
84432926
|
[1] |
HYD TUBE,10 mm OD
|
ZED
, Serial Range: -C719
|
| 6. |
84163010
|
[1] |
HYD TUBE,10 mm OD x 2349, 267 mm L
|
ZED
, Start Serial: D720
|
| 6. |
84007695
|
[1] |
HYD TUBE
|
ZED
, Serial Range: -C719
|
| 6. |
84163006
|
[1] |
HYD TUBE,10 mm OD x 2085, 437 mm L
|
ZED
, Start Serial: D720
|
| 7. |
84143574
|
[1] |
HYD TUBE,10 mm DIA
|
ZED
|
| 7. |
84131213
|
[1] |
HYD TUBE
|
ZED
|
| 8. |
84143572
|
[1] |
HYD TUBE,10 mm DIA
|
ZED
|
| 8. |
84131215
|
[1] |
HYD TUBE
|
ZED
|
| 9. |
87491157
|
[1] |
HYD TUBE,10 mm OD x 1172, 1138 mm L
|
ZED
|
| 9. |
87474973
|
[1] |
HYD TUBE,10 mm DIA x 1320, 1050 mm L
|
ZED
|
| 10. |
87491155
|
[1] |
HYD TUBE,10 mm DIA x 1228, 1112 mm L
|
ZED
|
| 10. |
87474975
|
[1] |
HYD TUBE,10 mm DIA x 1268, 1144 mm L
|
ZED
|
| 11. |
427419
|
[2] |
HYD CONNECTOR
|
ZED
|
| 12. |
431941
|
[1] |
SUPPORT
|
DUB
|
| 13. |
430357
|
[1] |
CLAMP
|
DUB
|
| 14. |
84007699
|
[2] |
COVER PLATE
|
ZED
|
| 15. |
84100035
|
[1] |
MOUNTING PLATE
|
ZED
|
| 16. |
120100
|
[1] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 17. |
86588450
|
[1] |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
|
ZED
|
| 18. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 19. |
9706755
|
[1] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 20. |
412152
|
[1] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 21. |
43118
|
[1] |
BOLT,Hex, M6 x 1.0 x 40mm, Cl 8.8
|
NH
Superseded by part number: 120102
|
| 22. |
397985
|
[4] |
BOLT,Hex, M6 x 70mm, Cl 8.8, Full Thd
|
NH
|
| 23. |
87493575
|
[2] |
NUT
|
ZED
|
