凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (07.12[01]) - TANDEM AUTO-STEER AXLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
679 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
734031
|
[2] |
HYD CONNECTOR,M16 x 1.5 Male x M16 x 1.5 Male x M16 x 1.5 Female
|
ZED
|
| 2. |
84432940
|
[1] |
HYD TUBE,10 mm OD
|
ZED
, Serial Range: -C719
|
| 2. |
87614608
|
[1] |
HYD TUBE,10 mm OD
|
ZED
, Start Serial: D720
|
| 2. |
84434149
|
[1] |
HYD TUBE
|
ZED
M10, Serial Range: -C719
|
| 2. |
87614606
|
[1] |
HYD TUBE,10 mm OD
|
ZED
, Start Serial: D720
|
| 3. |
412152
|
[1] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 4. |
86508569
|
[1] |
BOLT,Hex, M6 x 70mm, Cl 8.8
|
NH
|
| 5. |
84043962
|
[1] |
DRAINCOCK/TAP SUPPLY
|
ZED
|
| 6. |
84449414
|
[1] |
FLEXIBLE HOSE,7.94mm ID x 1960mm L, SAE 100R1
|
ZED
|
| 7. |
9813512
|
[2] |
HYD CONNECTOR
|
ZED
Superseded by part number: 89813512
|
| 8. |
368582
|
[3] |
STRAP
|
GI
Superseded by part number: 263117
|
| 9. |
433007
|
[2] |
CLAMP
|
ZED
|
| 10. |
433100
|
[1] |
SUPPORT
|
ZED
|
| 11. |
9839372
|
[1] |
CLAMP,11.1mm, Coat, 10.3mm Bolt Hole, P Type
|
ZED
, Start Serial: D700
|
