纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-044) - COVER ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
191 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY21C01114F5 | [1] | COVER | KOBCOVER ASSY |
| 3. | YT21C01034P2 | [1] | CATCH | KOB |
| 5. | YX21C01159F1 | [1] | LOCK | KOBASSY |
| 5-1. | YR22C01025P2 | [1] | LOCK | KOB |
| 5-2. | YX21C01188P1 | [1] | PLATE | KOB |
| 6. | ZS18C10020 | [6] | SCREW,Hex, M10 x 20mm | KOBCap |
| 7. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 8. | HY25X10027G1 | [6] | WASHER,10mm ID x 27mm OD x 3.2mm Thk | KOB |
| 9. | ZS18C06018 | [2] | SCREW,Hex, M6 x 18mm | KOBCAP |
| 10. | ZW26X06000 | [2] | LOCK WASHER | KOB |
| 11. | ZW16X06000 | [2] | WASHER | KOB Superseded by part number: 86588450 |
| 12. | YY21C01132P1 | [1] | ROD | KOB |
| 13. | YT21C01107P1 | [1] | BRACKET | KOB |
| 14. | YT21C01155P1 | [1] | WASHER | KOB |
| 15. | YT21C01053P1 | [2] | CLIP | KOB |
| 16. | YT21C01324P1 | [1] | COVER | KOB |
| 17. | YY21C01167D1 | [4] | RUBBER | KOB |
| 18. | YY21C01434D1 | [1] | COVER | KOBCOVER |
| 20. | YY21C01659P1 | [1] | SUPPORT | KOB |
| 20-8. | YT21C01225P1 | [2] | HINGE | KOB |
| 21. | PH21C01136DH | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
