神钢零件查询(K912) - MARK II EXCAVATOR ASN LC-2301 (11/88-12/03) (11-023) - CYLINDER ASSY (BUCKET) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
876 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1324F1 | [1] | CYLINDER | KOBASSY Superseded by part number: 2438U1324F2 |
| . . | 2438U1324F2 | [1] | CYLINDER | KOB |
| 1. | 24438U1324S1 | [1] | TUBE ASSY, CYLINDER | |
| 2. | 24438U1324S2 | [1] | ROD ASSY, PISTON | |
| 5. | 24438U778S3 | [1] | HEAD, CYLINDER | |
| 4. | 24438U1324S4 | [1] | BUSHING | |
| 5. | 24438U1324S5 | [1] | RING, SNAP | |
| 6. | 24438U1324S6 | [1] | RING, BUFFER , FOR F1 ONLY | |
| 7. | 24438U1324S7 | [1] | RING | |
| 8. | 24438U1324S8 | [1] | RING, BACK-UP | |
| 9. | 24438U1324S9 | [1] | RING, WIPER | |
| 10. | ZD12P14000 | [1] | O-RING | KOB |
| 11. | 2438U1324S11 | [1] | BACK-UP RING | KOB |
| 12. | 2438U1324S12 | [8] | CAPSCREW BOLT, SOCKET | CAPSCREW BOLT, SOCKET |
| 13. | 2438U1324S13 | [1] | SPACER | KOBBEARING, CUSHION |
| 14. | 2438U1324S14 | [1] | PISTON | KOB |
| 15. | 2438U1324S15 | [1] | SEALING RING | KOB |
| 16. | 2438U1324S16 | [2] | RING | KOB |
| 17. | 2438U1324S17 | [2] | RING | KOB |
| 18. | 2438U1324S18 | [1] | NUT | KOB |
| 19. | 2438U1324S19 | [1] | SHIM | KOB |
| 20. | 2438U1324S20 | [1] | PIN | KOB |
| 21. | 2438U1324S21 | [1] | SNAP RING | KOB |
| 22. | 2438U1324S22 | [2] | BUSHING | KOB |
| 23. | 2438U1323S23 | [4] | WIPER BLADE | KOB Superseded by part number: 2445R138D8 |
| 24. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 25. | 2438U1324S25 | [1] | BACK-UP RING | KOBFOR F2 ONLY |
| . . | 2438U1324R10 | [1] | REPAIR KIT | KOBF1 |
| . . | NSS | [1] | NOT SOLD SEPARAT | CONCONSISTS OF ITEM 4 TO 11, 15 TO 17 & 19 |
| . . | 2438U1324R20 | [1] | REPAIR KIT | KOBF1 & F2 |
| . . | 2438U1324R30 | [1] | REPAIR KIT F1 & F2 | REPAIR KIT F1 & F2 |
| . . | 2438U1324R40 | [1] | SEAL KIT | KOBREPAIR KIT( F2 ) |
| . . | 2438U1324R50 | [1] | REPAIR KIT | KOBF2 |
| . . | 2438U1324R100 | [1] | SEAL KIT | KOBREPAIR KIT(F1) |
| . . | 2438U1324R110 | [1] | REPAIR KIT | KOBF1 & F2 |
| . . | 2438U1324R200 | [1] | REPAIR KIT | KOBREPAI R KIT(F2) Superseded by part number: 2438U1324R200P |
