神钢零件查询(K912) - MARK II EXCAVATOR ASN LC-2301 (11/88-12/03) (11-022) - CYLINDER ASSY (ARM) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
120 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1323F1 | [1] | CYLINDER | KOBCYLINDER, ARM Superseded by part number: 2438U1323F2 |
| . . | 2438U1323F2 | [1] | CYLINDER | KOBCYLINDER, ARM |
| 1. | 2438U1323S1 | [1] | TUBE, CYLINDER | TUBE, CYLINDER |
| 2. | 2438U1323S2 | [1] | PISTON ROD | KOB |
| 3. | 2438U1323S3 | [1] | CYLINDER HEAD | KOB |
| 4. | 2438U1323S4 | [1] | BUSHING | KOB |
| 5. | 2438U1323S5 | [1] | SNAP RING | KOB |
| 6. | 2438U1323S6 | [1] | RING | KOBFOR F1 ONLY |
| 7. | 2438U1323S7 | [1] | RING | RING |
| 8. | 2438U1323S8 | [1] | RING, BACK-UP | RING, BACK-UP |
| 9. | 2438U1323S9 | [1] | RING, WIPER | RING, WIPER |
| 10. | ZD12P15000 | [1] | O-RING | KOB |
| 11. | 2438U1323S11 | [1] | BACK-UP RING | KOB |
| 12. | 2438U1323S12 | [8] | SCREW | KOB |
| 13. | 2438U1323S13 | [1] | BEARING | KOB |
| 14. | 2438U1323S14 | [1] | PISTON | KOB |
| 15. | 2438U1323S15 | [1] | SEALING RING | KOBSEALRING ASSY |
| 16. | 2438U1323S16 | [2] | RING | KOB |
| 17. | 2438U1323S17 | [2] | RING | RING |
| 18. | 2438U1323S18 | [1] | NUT | KOB |
| 19. | 2438U1323S19 | [1] | SHIM | KOB |
| 20. | 2438U1323S20 | [1] | PIN | KOB |
| 21. | 2438U1323S21 | [1] | SNAP RING | KOB |
| 22. | 2438U1323S22 | [2] | BUSHING | KOB |
| 23. | 2438U1323S23 | [4] | WIPER BLADE | KOB Superseded by part number: 2445R138D8 |
| 24. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| 25. | 2458U10786 | [1] | RING BUFFER FOR F2 ONLY | |
| . . | 2438U1323R10 | [1] | REPAIR KIT | KOBF1 |
| . . | NSS | [1] | NOT SOLD SEPARAT | CONCONSISTS OF ITEM 4 TO 11, 15 TO 17 &19 |
| . . | 2438U1323R20 | [1] | REPAIR KIT F1 & F2 | |
| . . | 2438U1323R30 | [1] | REPAIR KIT F1 & F2 | |
| . . | 2438U1323R40 | [1] | REPAIR KIT | KOBF2 |
| . . | 2438U1323R50 | [1] | REPAIR KIT | KOBF2 |
| . . | 2438U1323R100 | [1] | REPAIR KIT | KOBREPAIR KIT F1 |
| . . | 2438U1323R110 | [1] | REPAIR KIT | KOBREPAIR KIT F1 & F2 |
| . . | 2438U1323R200 | [1] | RIPPER | KOBREPAIR KIT F2 |
