凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (09.02[01]) - AUTOMATIC OILING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
288 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84818518
|
[1] |
LUBE PUMP
|
BEL
(2 to 7, 20, 22)
|
| 2. |
84818525
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
|
| 3. |
84819466
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
|
| 4. |
84819100
|
[1] |
HYDRAULIC VALVE
|
ZED
VALVE
|
| 5. |
84819098
|
[1] |
HYD CONNECTOR
|
ZED
|
| 6. |
84819099
|
[1] |
HYDRAULIC PUMP,12V
|
ZED
|
| 7. |
84819467
|
[1] |
WIRE HARNESS
|
ZED
|
| 8. |
84818662
|
[1] |
SUPPORT
|
ZED
|
| 9. |
84818517
|
[1] |
BRUSH
|
ZED
|
| 10. |
84818521
|
[2] |
MANIFOLD
|
ZED
|
| 11. |
84807296
|
[1] |
PLUG
|
ZED
|
| 13. |
84807243
|
[1] |
HYD CONNECTOR
|
ZED
18" - 4 MM
|
| 14. |
87344244
|
[1] |
REDUCER
|
ZED
|
| 15. |
84818522
|
[1] |
REDUCER
|
ZED
|
| 16. |
84818519
|
[1] |
HOSE,5000mm L
|
ZED
DIA. 4 MM
|
| 17. |
84818520
|
[1] |
HOSE
|
ZED
DIA. 8 MM
|
| 18. |
84819097
|
[1] |
HYD CONNECTOR
|
ZED
|
| 19. |
89832305
|
[1] |
WASHER
|
ZED
Superseded by part number: 9832305
|
| 20. |
84801563
|
[1] |
FILLER CAP
|
ZED
|
| 21. |
335021
|
[1] |
CLAMP,12mm ID, 6.4mm Bolt Hole, P Type
|
ZED
|
| 22. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
|
