纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-001) - FRAME ASSY, UPP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
845 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW52F00043F1 | [1] | FRAME GROUP, UPP | |
| A1. | PW52F00044P1 | [1] | FRAME, UPP | |
| A1-1. | PW52F00042P1 | [1] | FRAME, UPP | |
| A1-1a. | PW52F01355P1 | [1] | BRACKET | |
| A1-1b. | PW52F01230P1 | [2] | BUSHING,65mm ID x 80mm OD x 65mm L | KOB |
| A2. | ZG91U02000 | [1] | LUBE NIPPLE | KOB |
| A3. | PW52F01387P1 | [1] | STOP | KOBSTOPPER |
| A4. | ZS18C12070 | [15] | SCREW,Hex, M12 x 70mm | KOB |
| A5. | HS58C12070G2 | [1] | BOLT | KOB |
| A6. | ZS18C12040 | [2] | SCREW,Hex, M12 x 40mm | KOB |
| A7. | ZW16H12000 | [2] | WASHER | KOB |
| A9. | PW52F01330P1 | [1] | PLATE | KOB |
| A10. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| A11. | ZW16X10000 | [2] | WASHER | KOB |
| A12. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOB |
| A13. | PW52F01309P1 | [1] | FOAM INSULATION | KOB |
| A14. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| . . | PW24C00005F1 | [1] | COVER ASSY, UNDER | |
| B1. | PW24C01039P1 | [1] | COVER | KOBCOVER |
| B2. | PW24C01042P1 | [1] | COVER | KOBCOVER |
| B3. | PM24C01041P1 | [1] | COVER | KOBCOVER Superseded by part number: PW24C01041P1 |
| B4. | ZM73C10020 | [11] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
