纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-002) - BRACKET ASSY, SWING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
614 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX02B00150F1 | [1] | BRACKET GROUP,SWING | |
| A1. | PX02B01268P1 | [2] | PLATE | |
| A2. | PX02B01269P1 | [1] | PLATE | |
| A3. | PX02B01270P1 | [1] | PLATE | KOBPLATE |
| A4. | PX02B01266P1 | [1] | GASKET | KOBRUBBER |
| A5. | PX02B01209P1 | [1] | GROMMET | KOB |
| A6. | ZS18C10100 | [2] | SCREW,Hex, M10 x 100mm | KOBCAP |
| A7. | ZS28C10055 | [2] | SCREW,Hex Socket Head, M10 x 55mm | KOBCAP |
| A8. | ZW16H10000 | [2] | WASHER | KOBWASHER |
| A9. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| A10. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOB |
| A11. | PY01P01043D4 | [1] | CABLE TIE,4.80mm W x 251mm L | KOB |
| A12. | PX02B01267P1 | [2] | RUBBER STRIP | KOBRUBBER |
| A13. | PX02B00128F1 | [1] | BRACKET | KOBBRACKET ASSY, SWING |
| A13-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBRACKET, SWING |
| A13-2. | PX02B01147P1 | [1] | BUSHING | KOB |
| . . | PX02B00147F1 | [1] | CYLINDER INSTAL | |
| B1. | PX02B01241P1 | [1] | PIN,48mm OD x 143mm L | KOB |
| B3. | PM02B01220P1 | [1] | PLATE | KOB Superseded by part number: 72271886 |
| B4. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| B5. | ZS18C12030 | [1] | SCREW,Hex, M12 x 30mm | KOBCAP |
| B7. | ZW26X12000 | [1] | WASHER | KOB |
| B8. | 2418T12345 | [1] | WASHER | KOB |
| B9. | YJ12B01097P1 | [2] | SHIM,47mm ID x 70mm OD x 0.5mm Thk | KOB |
| B10. | PR02B01121D1 | [4] | SHIM,47mm ID x 70mm OD x 0.9mm Thk | KOB |
| B11. | PX01V00042F2 | [1] | HYDRAULIC CYLINDER,Double Acting, 45mm Rod, 488mm Stroke | KOBCYLINDER ASSY, SWING |
| . . | PX02B00149F1 | [1] | BRACKET INSTAL, SWING | |
| C1. | PX02B01239P1 | [1] | PIN,70mm OD x 163mm L | KOB |
| C2. | PX02B01275P1 | [1] | PIN,65mm OD x 134mm L | KOBPIN |
| C3. | PX02B01274P1 | [1] | PLATE | KOBPLATE |
| C4. | PW02B01226P1 | [1] | WASHER | KOB |
| C5. | 2445R138D4 | [2] | SEAL,65mm ID x 80mm OD x 4mm Thk | KOBDUST |
| C6. | PW02B01224P1 | [1] | SHIM,0.5mm Thk | KOB |
| C7. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOB |
| C8. | HS18C12150G1 | [1] | SCREW | KOBCAPSCREW Superseded by part number: 44151 |
| C10. | ZN18C12010 | [2] | NUT | KOB |
