纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-006) - ENGINE INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
115 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW02P00011F1 | [1] | ENGINE INSTAL | |
| 2. | PW02P01055P1 | [1] | BRACKET | KOB |
| 3. | PW02P01056P1 | [1] | BRACKET | KOB |
| 6. | PW02P01054D1 | [6] | RUBBER MOUNTING | KOB |
| 7. | PW02P01054D2 | [2] | RUBBER MOUNTING | KOB |
| 8. | PW01P01022P1 | [4] | WASHER | KOB |
| 10. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOB |
| 11. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBCAP |
| 12. | ZS18C12120 | [4] | SCREW,Hex, M12 x 120mm | KOBCAP |
| 13. | ZW16H10000 | [8] | WASHER | KOB |
| 14. | ZW16H12000 | [4] | WASHER | KOB |
| 22. | PW02P00015F1 | [1] | ENGINE | KOBENGINE ASSY |
| 23. | PW02P01057F1 | [1] | PLUG | KOBASSY |
| 23-2. | LQ02PU1002S002 | [1] | WASHER | KOB |
| 23-3. | LQ02PU1002S003 | [1] | BODY | KOB |
| 23-4. | LQ02PU1002S004 | [1] | O-RING | KOB |
| 23-5. | LQ02PU1002S005 | [1] | CAP | KOB |
| 23-6. | LQ02PU1002S006 | [1] | PLUG | KOB |
| 24. | PW02P01041P1 | [4] | COVER | KOB |
| 25. | PW02P01047D1 | [1] | HOSE,12mm ID x 250mm L | KOB |
