| 1. |
100020
|
[6] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 2. |
87531396
|
[1] |
SUPPORT
|
ZED
|
| 3. |
445394
|
[1] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 4. |
9706755
|
[4] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 5. |
322357
|
[4] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 6. |
120056
|
[4] |
BOLT,M6 x 1.0 x 54.15mm, Cl 8.8
|
NH
|
| 7. |
87531929
|
[1] |
DRAWBAR
|
ZED
|
| 8. |
84128880
|
[1] |
SUPPORT
|
ZED
|
| 9. |
87532958
|
[1] |
BRACKET
|
ZED
|
| 10. |
430356
|
[8] |
CLAMP
|
ZED
|
| 11. |
84814948
|
[4] |
SUPPORT
|
ZED
|
| 12. |
84056523
|
[16] |
BOLT,Hex, M16 x 45mm, Cl 10.9
|
ZED
|
| 13. |
140048
|
[25] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 14. |
392530
|
[16] |
NUT,M16, Cl 10
|
NH
|
| 15. |
120245
|
[3] |
CARRIAGE BOLT,Short Sq Nk, M10 x 30mm, Cl 8.8, Full Thd
|
ZED
Superseded by part number: 86512446
|
| 16. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 17. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 18. |
43168
|
[3] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 19. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 20. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 21. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 22. |
308761
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 23. |
86508584
|
[6] |
BOLT,Hex, M16 x 170mm, Cl 8.8
|
ZED
|
| 24. |
84111710
|
[1] |
DIA KIT, HARVESTER
|
ATT
(28, 31) D= 33, Serial Range: -C867
|
| 24. |
84229178
|
[1] |
KIT
|
ZED
(28, 31) D= 31, Start Serial: D868
|
| 24. |
84110275
|
[1] |
DIA KIT, HARVESTER
|
ATT
(28, 31) D= 42
|
| 24. |
84110276
|
[1] |
DIA KIT, HARVESTER
|
ATT
(28, 31) D= 41 Superseded by part number: 6042690070, 84442663, 84111660
|
| 25. |
87559152
|
[1] |
TOW HOOK
|
ZED
|
| 26. |
84790051
|
[1] |
BUSHING
|
ZED
|
| 27. |
412689
|
[1] |
LOCK PIN,8mm OD x 50mm L, Slotted
|
NH
|
| 28. |
84442666
|
[1] |
DRIVE BUSHING
|
ZED
D= 33, Serial Range: -C867 Superseded by part number: 84111658
|
| 28. |
84229182
|
[1] |
BUSHING,31mm ID x 56mm OD x 24mm L
|
ZED
D= 31, Start Serial: D868
|
| 28. |
84442665
|
[1] |
BUSHING,42mm ID x 56mm OD x 24mm L
|
PA
D= 42
|
| 28. |
84442667
|
[1] |
BUSHING
|
PA
D= 41 Superseded by part number: 84111660
|
| 29. |
87580271
|
[1] |
HITCH
|
ZED
|
| 30. |
84041686
|
[1] |
CHAIN
|
ZED
|
| 31. |
84442663
|
[1] |
HINGE,52.3mm ID x 90mm OD x 33mm L
|
ZED
|
| 32. |
87588695
|
[1] |
TOW HOOK
|
ZED
|
| 33. |
9839053
|
[1] |
PIN,98mm OD x 76.5mm L
|
ZED
|
| 34. |
9839054
|
[1] |
NUT
|
ZED
|
| 35. |
84045754
|
[1] |
CLAMP BRACKET
|
ZED
|
| 36. |
84045753
|
[1] |
CABLE
|
ZED
, Serial Range: -C699 Superseded by part number: 84159558
|
| 36. |
84159558
|
[1] |
CABLE
|
ZED
, Start Serial: D700
|
| 36. |
84056519
|
[1] |
CABLE
|
ZED
, Serial Range: -C699 Superseded by part number: 84159559
|
| 36. |
84159559
|
[1] |
CABLE
|
ZED
, Start Serial: D700
|
| 37. |
89837598
|
[1] |
SCREW
|
ZED
Superseded by part number: 87015585
|
| 38. |
84041908
|
[1] |
BUSHING
|
ZED
|
| 39. |
89837597
|
[1] |
NUT
|
ZED
Superseded by part number: 9837597
|
| 40. |
84041795
|
[1] |
WASHER,26mm ID x 82mm OD x 10mm Thk
|
ZED
|
| 41. |
851086
|
[1] |
CHAIN
|
NH
Superseded by part number: 854993
|
| 41. |
1032162
|
[1] |
CHAIN
|
CAS
|
| 45. |
84195309
|
[1] |
HITCH
|
ZED
, Serial Range: -F744859 Superseded by part number: 84324117
|
| 45. |
84324117
|
[1] |
HITCH
|
ZED
, Start Serial: D860
|
| 46. |
84435244
|
[4] |
BOLT,Hex, M16 x 180mm, Cl 8.8
|
ZED
, Start Serial: D744
|
| 49. |
412183
|
[1] |
CARRIAGE BOLT,Short Sq Nk, M10 x 35mm, Cl 8.8
|
DUB
, Start Serial: D752 Superseded by part number: 9833222
|
| 50. |
87580270
|
[1] |
HITCH
|
ZED
|
