凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (12.03[01]) - JACK Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
590 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87528604
|
[1] |
JACK
|
ZED
(2 to 19), Serial Range: -C707
|
| 1. |
84146532
|
[1] |
JACK
|
ZED
(2 to 19), Start Serial: D708 Superseded by part number: 87528604
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
|
| 4. |
84400422
|
[1] |
THREADED ROD
|
ZED
|
| 5. |
84400423
|
[1] |
COVER
|
ZED
|
| 6. |
84400424
|
[1] |
HANDLE
|
ZED
|
| 7. |
84400425
|
[1] |
BALL BEARING
|
ZED
|
| 9. |
84400426
|
[1] |
GEAR
|
ZED
Z= 14
|
| 10. |
84400427
|
[1] |
GEAR
|
ZED
Z= 32
|
| 11. |
300872
|
[1] |
LOCK PIN,8mm OD x 36mm L, Slotted
|
GI
|
| 12. |
300871
|
[1] |
LOCK PIN,M8 x 30, Slotted
|
PA
Superseded by part number: 80300871
|
| 13. |
84400428
|
[1] |
PIN
|
ZED
|
| 15. |
450300
|
[1] |
COTTER PIN
|
PA
|
| 16. |
300919
|
[2] |
LUBE NIPPLE
|
ZED
Superseded by part number: 84447449
|
| 17. |
43442
|
[4] |
NUT
|
NH
Superseded by part number: 126712A1, 126712A1, 86629542
|
| 19. |
84400429
|
[2] |
BUSHING
|
ZED
|
