神钢零件查询(K912) - MARK II EXCAVATOR ASN LC-2301 (11/88-12/03) (05-019) - HEATER ASSY (FOR EXPORT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
508 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J11210F1 | [1] | HEATER ASSY | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 2. | 2418P18847 | [1] | BRACKET | |
| 3. | 2479Z961 | [1] | VALVE | KOB |
| 4. | 2427P2867 | [1] | PANEL | |
| 5. | 2444Z2354D2 | [2] | FLEXIBLE HOSE | KOB |
| 6. | 2444Z2220D1 | [1] | HOSE | KOB |
| 7. | ZW16K05000 | [4] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 8. | 2444Z2220D5 | [1] | FLEXIBLE HOSE | KOB |
| 9. | ZC15X06000 | [4] | CLIP | KOB |
| 10. | ZC15X02300 | [6] | CLIP | KOB |
| 11. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 12. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 13. | ZS18C06025 | [2] | SCREW,Hex, M6 x 25mm | KOBM06x1.0x25mm |
| 14. | 2420T4556 | [4] | SCREW | KOB |
| 15. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 16. | ZW16X10000 | [8] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 17. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 18. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 19. | ZW26X08000 | [3] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 20. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 21. | 2418T10455 | [2] | PIPE | KOB |
| 22. | 2406R240D3 | [1] | FLEXIBLE CONTROL | KOBCABLE CONTROL |
| 23. | 2479Z1805 | [1] | HARNESS | |
| 24. | 2432Z290 | [14] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 25. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| 26. | 2420Z699 | [1] | GROMMET | KOB |
| 27. | R44T0180 | [1] | COCK | KOB |
| 28. | R44T0201 | [1] | HYD CONNECTOR | KOB Superseded by part number: 113700-1381 |
| 29. | R16T0238D1 | [4] | CLIP | KOB |
| 30. | R18T0026D17 | [1] | HOSE | KOBID 12 x OD 22 x 3300mm |
| 31. | R18T0026D13 | [1] | HOSE | KOBID 12 x OD 22 x 3800mm |
| 32. | 2444T2651 | [1] | HYD CONNECTOR | KOB |
| 33. | 2479Z1804 | [1] | WIRE HARNESS | KOB |
| 34. | ZC47X22014 | [4] | CLIP | KOB Superseded by part number: ZC48X22014 |
| 35. | ZC45X22011 | [1] | CLIP | KOBClamp -- Ø22mm Single Cable Superseded by part number: ZC46X22011 |
| 36. | ZS18C08014 | [1] | SCREW,Hex, M8 x 14mm | KOBM08x1.25x14mm |
| 37. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 38. | ZW26X05000 | [4] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 39. | 2444Z2220D7 | [1] | HOSE | KOB |
