纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-015[01]) - CONTROL ASSY, ENGINE (WITH DECEL) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
886 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW11M00010F1 | [1] | CONTROL ASSY, ENGINE | |
| 1. | PH51M00011F1 | [1] | LEVER ASSY. | KOBTHROTTLE |
| 1-1. | PH51M01030P1 | [1] | BRACKET | KOBBRACKET |
| 1-2. | PH51M01032P1 | [1] | LEVER | KOBLEVER |
| 1-3. | R16T0137D2 | [6] | WASHER | KOB |
| 1-4. | ZW16H12000 | [1] | WASHER | KOB |
| 1-5. | PM51M01026P1 | [2] | BUSHING,12mm ID x 14mm OD x 7mm L | KOB |
| 1-6. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 1-7. | 2420T8007D3 | [1] | CAPSCREW | KOBSCREW |
| 1-8. | PM51M01025P1 | [1] | PLATE | KOB |
| 1-9. | ZN17C12007 | [2] | NUT | KOB Superseded by part number: ZN18C12007 |
| 2. | PW11M01100P1 | [1] | CABLE | KOBCONTROL |
| 3. | PW11M01153F1 | [1] | LINK ASSY. | KOB |
| 3-1. | PW11M01094P1 | [1] | BRACKET | KOB |
| 3-2. | PW11M01152F1 | [1] | LINK ASSY. | KOB |
| 3-2A. | PW11M01116P2 | [1] | LINK | KOB Superseded by part number: PW11M01152F1 |
| 3-2B. | 2405R312D1512 | [1] | BUSHING,15mm ID x 17mm OD x 12mm L | KOB |
| 3-3. | PW11M01112P1 | [1] | NUT | KOB Superseded by part number: PW11M01112P2 |
| 3-4. | YR21C01161P1 | [1] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOB |
| 3-5. | PW11M01107P1 | [1] | SPRING | KOB |
| 4. | 2406Z321 | [1] | HANDLE | KOB |
| 5. | YT11M01012P1 | [1] | GROMMET | KOB Superseded by part number: YR03M01293P1 |
| 6. | PW11M01071P1 | [1] | PIN,8mm OD x 19mm L | KOB |
| 7. | PW11M01109P2 | [1] | PIN | KOB |
| 8. | ZR36X00600 | [1] | SNAP RING | KOB |
| 9. | ZS18C05010 | [1] | SCREW,Hex, M5 x 10mm | KOB |
| 10. | 2419R9D2 | [1] | COTTER PIN | KOB |
| 11. | PM50S00005P1 | [1] | SWITCH | KOB |
| 12. | ZM22C10025 | [1] | BOLT | KOB |
| 13. | ZM22C08020 | [6] | BOLT | KOB |
| 14. | ZW16X08000 | [1] | WASHER | KOB |
| 15. | PW11M01194D1 | [1] | TUBE | KOBTUBE |
| 16. | PW20S00012F1 | [1] | GOVERNOR | KOBMOTOR ASSY |
| 18. | ZC46X06007 | [2] | CLIP | KOB |
| 19. | ZM61C06016 | [2] | BOLT | KOB |
| 20. | PW11M01108P1 | [1] | GROMMET | KOB |
| 16-1. | PW20S00012S001 | [1] | CABLE | KOB Superseded by part number: PW20S00012F1 |
| 16-2. | PM20S00009S002 | [1] | GOVERNOR | KOB |
| 16-3. | PW20S00012S003 | [1] | BRACKET | KOB |
| 16-4. | PM20S00009S004 | [3] | SCREW | KOBCAP |
| 16-5. | PM20S00009S005 | [1] | LEVER ASSY. | KOB |
| 16-6. | PM20S00009S006 | [1] | LOCK WASHER | KOB |
| 16-7. | PM20S00009S007 | [1] | NUT | KOB |
| 16-8. | PM20S00009S008 | [1] | RING | KOB |
| 16-9. | PM20S00009S009 | [1] | COVER | KOB |
| 16-10. | PM20S00009S010 | [2] | SCREW | KOBCAP Superseded by part number: ZM46C04016 |
