| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J10386F1 | [1] | INSTAL,LOW | |
| 1. | 2422J2745 | [1] | FRAME,LOW | |
| 2. | NSS | [2] | NOT SOLD SEPARAT | CONIDLER ASSY, P.451-01 |
| 3. | NSS | [14] | NOT SOLD SEPARAT | CONROLLER ASSY,LOW, P.461-01 |
| 4. | NSS | [4] | NOT SOLD SEPARAT | CONROLLER ASSY,UPP, P.467-01 |
| 5. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING ASSY,TRACK, P.474-01 |
| 6. | 2441U787F1 | [2] | HYDRAULIC MOTOR | KOB Superseded by part number: 2441U787F3 |
| 7. | 2404N256 | [2] | SPROCKET | SPROCKET |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONBEARING |
| 9. | 24100J5144F4 | [1] | FLEXIBLE JOINT | KOB Superseded by part number: 24100U1524F1 |
| 10. | ZS18C16120 | [1] | CAPSCREW,Hex, M16 x 120mm | KOBSCREW M16x2.0x120mm |
| 11. | 2420Z1622 | [36] | CAPSCREW | CAPSCREW |
| 12. | ZS18C20130 | [4] | CAPSCREW,Hex, M20 x 130mm | KOBSCREW M20x2.50x130mm |
| 13. | 2420Z1254 | [36] | SCREW | KOB |
| 14. | ZS18C10014 | [4] | SCREW,Hex, M10 x 14mm | KOBM10x1.50x14mm |
| 15. | ZN18C16013 | [1] | NUT | KOBM16x2.0mm |
| 16. | ZN18C20016 | [4] | NUT | KOBM20x2.5mm |
| 17. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 18. | 2414P4770 | [2] | GUIDE | KOB Superseded by part number: 2414P4770K |
| 19. | 2420Z1671 | [8] | CAPSCREW | CAPSCREW |
| 20. | ZW16H20000 | [44] | WASHER | KOBID 21 x OD 40 x Th 4.5mm |
| 21. | ZW16H24000 | [8] | WASHER | KOBID 25 x OD 48 x Th 6.0mm |
| 22. | 2414T1597 | [1] | COVER | KOB |
| 23. | 2418T8720 | [1] | PACKING | KOB |
| 24. | 2414N3672D1 | [1] | COVER | |
| 25. | 2414N3672D2 | [1] | COVER | |
| 26. | 2420Z1623 | [56] | SCREW | KOB Superseded by part number: 2420Z1309 |
| 27. | ZS13C12025 | [3] | SCREW | KOBM12x1.75x25mm Superseded by part number: ZS18C12025 |
| 28. | ZW16H22000 | [56] | WASHER | KOBID 23 x OD 44 x Th 6.0mm |
| 29. | ZW11X12000 | [3] | WASHER | KOBID 12 x OD 24 x Th 2.3mm Superseded by part number: ZW16X12000 |
| 30. | ZS18C16025 | [12] | SCREW,Hex, M16 x 25mm | KOBM16x2.0x25mm |
| 31. | ZW26X16000 | [12] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 32. | ZS18C20050 | [52] | SCREW,Hex, M20 x 50mm | KOBM20x2.50x50mm |
| 33. | ZW16X16000 | [12] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
