纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-031[02]) - CONTROL LINES, REMOTE (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
444 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW64H00037F1 | [1] | VALVE INSTAL, (RIGHT SIDE STD) | |
| A1. | PX30V00043F1 | [1] | VALVE | KOBASSY,PILOT |
| A2. | ZS28C06030 | [4] | SCREW,Hex Socket Head, M6 x 30mm | KOB |
| A3. | ZW16X06000 | [4] | WASHER | KOB Superseded by part number: 86588450 |
| A4. | 2444Z2525 | [1] | HYD CONNECTOR | KOB |
| A5. | HH35S04004G1 | [2] | 90 ELBOW | KOB |
| A6. | HH25S04004G3 | [1] | HYD CONNECTOR | KOB |
| A8. | HH45S06004G1 | [1] | ELBOW | KOB |
| A9. | 2444Z2894 | [1] | 90 ELBOW | KOB |
| A10. | HH25S04004G1 | [1] | HYD CONNECTOR | KOB Superseded by part number: 72283606 |
| A11. | PU64H01002P1 | [1] | ADAPTER | KOBADAPTER |
| . . | PW64H00038F1 | [1] | VALVE INSTAL, (LEFT SIDE STD) | |
| B5. | HH25S06004G1 | [1] | HYD CONNECTOR | KOB Superseded by part number: HH25S06004G3 |
| C1. | HX33L03135DR | [1] | HOSE,4.8mm ID x 1350mm L | KOB |
| C2. | HX23L03110DB | [1] | HOSE,4.8mm ID x 1100mm L | KOB |
| C3. | HX33L03105DG | [1] | HOSE | KOBHOSE |
| C4. | HX23L03115DH | [1] | HOSE | KOBHOSE |
| C5. | HX23L03340DH | [1] | HOSE | KOBHOSE |
| C6. | HX23L03360DR | [1] | HOSE | KOBHOSE |
| C7. | HX23L03280DB | [1] | HOSE | KOBHOSE |
| C8. | HX23L03270DG | [1] | HOSE | KOBHOSE |
| C9. | HX34L04185DX | [1] | HOSE,6.3mm ID x 1850mm L | KOB |
| C10. | HX24L04340DX | [1] | HOSE,6.3mm ID x 3400mm L | KOB |
| C11. | PW68H01023DL | [1] | HOSE | KOBHOSE |
| C12. | PW68H01023D5 | [1] | HOSE,9.5mm ID x 2090mm L | KOB |
| C13. | ZC16X01800 | [2] | CLIP | KOB |
| C14. | ZC46X38014 | [1] | CLIP | KOB |
| C15. | ZC46X46014 | [1] | CLIP | KOB |
| C16. | ZS18C12020 | [2] | SCREW,Hex, M12 x 20mm | KOB |
| C17. | ZW16H12000 | [2] | WASHER | KOB |
| C18. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOB |
| C19. | PY01P01043D8 | [5] | CABLE TIE,102mm L | KOB |
| C21. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOB |
| C22. | PM68H01057P1 | [1] | COVER | KOB |
| C24. | ZW16H08000 | [1] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| C25. | PW68H01041P1 | [1] | CLAMP | KOB |
| C26. | PM68H01054P1 | [1] | FOAM INSULATION | KOB |
| C27. | PM68H01055P1 | [1] | FOAM INSULATION | KOB |
| C28. | PH68H01042P1 | [1] | RUBBER | KOB |
