纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-033) - CONTROL LINES, REMOTE (DOZER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
964 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW68H00024F1 | [1] | CONTROL LINES, REMOTE | |
| 1. | 2444Z2525 | [2] | HYD CONNECTOR | KOB |
| 2. | HH35S04004G2 | [1] | ELBOW | KOB |
| 3. | HH35S04004G1 | [1] | 90 ELBOW | KOB |
| 4. | PY01P01043D6 | [1] | CABLE TIE,4.80mm W x 383mm L | KOB |
| 5. | 2444Z2894 | [2] | 90 ELBOW | KOB |
| 6. | HX24L04180DX | [1] | HOSE ASSY. | KOB |
| 7. | PW68H01024D3 | [1] | HOSE | KOB |
| 8. | HX33L03042DX | [1] | HOSE,4.8mm ID x 420mm L | KOB |
| 9. | HX33L03038DX | [1] | HOSE | KOB Superseded by part number: HX33L03040DX |
| 10. | PB30V00002F1 | [1] | PILOT VALVE | KOB Superseded by part number: PB30V00002F2 |
| 11. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOB |
| 12. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 13. | ZC16X01800 | [1] | CLIP | KOB |
| 15. | HH25S06004G1 | [1] | HYD CONNECTOR | KOB Superseded by part number: HH25S06004G3 |
| 16. | PU64H01002P1 | [1] | ADAPTER | KOB |
