纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-042) - GUARD ASSY, HEAD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
752 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW25C00003F1 | [1] | GUARD | KOBASSY, HEAD |
| 1. | PW02C01240P3 | [1] | GUARD | KOBGUARD |
| 2. | ZM22C08060 | [6] | BOLT | KOBSEMS-BOLT |
| 4. | YT50C01022P1 | [6] | SEAL,15mm ID x 30mm OD x 2mm Thk | KOB |
| 5. | ZS18C10016 | [1] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| 6. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOB |
| 7. | ZW26K10000 | [4] | LOCK WASHER | KOB |
| 8. | ZW16K10000 | [4] | WASHER | KOB |
