纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-043) - WINDOW ASSY, FR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
318 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW50C00002F1 | [1] | WINDOW | KOBWINDOW ASSY, FR. |
| 1. | PW50C01007P1 | [1] | FRAME ASSY | KOB |
| 2. | PW50C01008P1 | [2] | BRACKET | KOB |
| 3. | PM76S00001F1 | [1] | WIPER MOTOR | KOB Superseded by part number: PY76S00001P1 |
| 4. | PM53C00001P1 | [1] | WIPER ARM | KOB |
| 5. | YR53C01001P1 | [1] | WIPER BLADE | KOB Superseded by part number: EN53C00003P1 |
| 6. | YT02C01125P1 | [1] | COVER | KOB |
| 7. | YT50C01024P1 | [2] | ROLLER | KOB |
| 8. | PW50C01017P2 | [1] | SEAL, GLASS | KOBSEAL,WINDOW SEAL |
| 9. | PW50C01018P1 | [1] | SEAL,684mm L | KOB |
| 10. | YT50C01023P1 | [4] | RUBBER | KOB Superseded by part number: YN02C01176D3 |
| 11. | YT02C01106P1 | [1] | HARNESS | KOB |
| 12. | YT50C01022P1 | [5] | SEAL,15mm ID x 30mm OD x 2mm Thk | KOB |
| 13. | YT50C01020P1 | [3] | RETAINER | KOB |
| 14. | YT02C01241D1 | [3] | BOLT | KOB |
| 15. | YR21C01161P1 | [3] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOB |
| 16. | ZW16X14000 | [3] | WASHER | KOB |
| 17. | YT22A01001P1 | [1] | STRAP | KOB |
| 18. | PY01P01043D2 | [11] | CABLE TIE,4.60mm W x 202mm L | KOBWire Ties -- 160mm Long Superseded by part number: YT50C01100P1 |
| 19. | PW50C01001P1 | [1] | GLASS | KOB |
| 20. | PM02C01447F1 | [1] | LOCK ASSY | KOBL.H. |
| 20-1. | PM02C01402P1 | [1] | BRACKET | KOB |
| 20-2. | PM02C01302P1 | [1] | PLATE | KOB |
| 20-3. | PM02C01303P1 | [1] | SPRING | KOB |
| 20-4. | 2405U104D014020 | [1] | BUSHING | KOB |
| 20-5. | PM02C01395P1 | [1] | PIN | KOB |
| 20-6. | ZW26X10000 | [1] | LOCK WASHER | KOB |
| 20-7. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 21. | PM02C01448F1 | [1] | LOCK ASSY | KOBR.H. |
| 21-1. | PM02C01403P1 | [1] | BRACKET | KOB |
| 21-2. | PM02C01306P1 | [1] | PLATE | KOB |
| 21-3. | PM02C01307P1 | [1] | SPRING | KOB |
| 22. | ZM66C06020 | [10] | BOLT | KOB |
| 25. | PM50C01051P1 | [2] | STOP | KOB |
| 26. | PM50C01042P1 | [2] | SHIM,1.0mm Thk | KOB |
| 27. | PM50C01052P1 | [4] | SHIM,1.0mm Thk | KOB |
| 28. | YT51C01058D1 | [2] | SCREW | KOBTAPPING |
