纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-044) - DOOR ASSY, CAB New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
424 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PM51C00006F1 | [1] | DOOR ASSY. | KOBCAB Superseded by part number: PM51C00006F1%LD |
| 1. | PM51C01071P1 | [1] | DOOR | KOB Superseded by part number: PM51C00006F1%LD |
| 2. | PM02C01074P1 | [1] | GLASS | KOB |
| 3. | PM02C01075P1 | [1] | GLASS | KOB |
| 5. | PM02C01489P1 | [1] | SEAL | KOB |
| 6. | PM51C01076D1 | [1] | SEAL | KOB |
| 7. | YR02C01465P1 | [1] | HANDLE | KOB |
| 8. | PH02C01074P2 | [1] | HANDLE | KOBASSY |
| 9. | PY02C01035P2 | [1] | COVER | KOB |
| 10. | PM02C01479P1 | [1] | HANDLE | KOB |
| 11. | YR22C01025P2 | [1] | LOCK | KOBKEY ASSY |
| 12. | 24100U1335 | [3] | LATCH | KOB |
| 13. | PM02C01342P1 | [1] | BRACKET | KOBASSY |
| 14. | PM02C01497P1 | [1] | LINK ASSY. | KOB |
| 15. | PH02C01076P2 | [1] | PLATE ASSY. | KOB |
| 16. | PM51C01068P1 | [1] | ROD | KOB Superseded by part number: PM51C01068P2 |
| 17. | PM02C01498P2 | [1] | ROD | KOB Superseded by part number: PM02C01498P3 |
| 18. | PM02C01156P1 | [1] | ROD | KOB Superseded by part number: PM02C01156P2 |
| 19. | PM51C01044P1 | [1] | ROD | KOB Superseded by part number: PM51C01044P2 |
| 20. | PM51C01043P1 | [1] | ROD | KOB Superseded by part number: PM51C01043P2 |
| 21. | PM51C01057P1 | [1] | ROD | KOB Superseded by part number: PM51C01057P2 |
| 22. | PM51C01054P1 | [1] | BRACKET | KOB |
| 23. | PM51C01050P1 | [1] | COVER | KOB |
| 24. | PH02C01082P2 | [1] | WIRE | KOB |
| 25. | YR02C01480P2 | [3] | SPRING | KOB |
| 26. | YT02C01066P1 | [1] | STOP | KOB |
| 27. | PM02C01172D2 | [1] | SEAL,7mm W x 4.8mm H x 2500mm L | KOB Superseded by part number: YR02C01511D2 |
| 28. | PM02C01172D1 | [1] | SEAL,7mm W x 4.8mm H x 3000mm L | KOB Superseded by part number: YR02C01511D4 |
| 29. | YR02C01486P2 | [8] | HOLDER | KOB |
| 30. | YR02C01485P2 | [3] | HOLDER | KOB |
| 31. | ZM66C06016 | [6] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 32. | ZM66C06012 | [2] | BOLT | KOB |
| 33. | ZS28C06012 | [2] | CAPSCREW,Hex Socket Head, M6 x 12mm | KOBSCREW CAP |
| 34. | ZM46C06012 | [6] | SCREW | KOBMACHINE |
| 35. | HN17C06000G1 | [2] | NUT | KOB |
| 36. | ZN17F10008 | [1] | NUT | KOB Superseded by part number: ZN18F10008 |
| 37. | PM51C01041P1 | [1] | NUT | KOB |
| 38. | ZN16C04003 | [1] | NUT | KOB Superseded by part number: ZN18C04003 |
| 39. | PM51C01042P1 | [1] | NUT | KOB |
| 40. | ZN17C06005 | [2] | NUT | KOB Superseded by part number: ZN18C06005 |
| 41. | ZW26K06000 | [2] | LOCK WASHER | KOBWASHER, LOCK |
| 42. | ZW16P05000 | [4] | WASHER | KOB |
| 43. | ZW16X10000 | [1] | WASHER | KOB |
| 44. | YT02C01246P1 | [4] | PLATE | KOB |
| 45. | YR03M01319D1 | [4] | SEAL | KOB |
| 46. | ZS18C06020 | [6] | SCREW,Hex, M6 x 20mm | KOBCAP |
| 47. | ZW16X06000 | [8] | WASHER | KOB Superseded by part number: 86588450 |
| 48. | ZW26X06000 | [2] | LOCK WASHER | KOB |
| 49. | PM02C01354D2 | [1] | SOFT TRIM | KOBTRIM |
| 50. | PM02C01354D3 | [1] | DOOR SEAL | KOBTRIM |
