神钢零件查询(K912) - MARK II EXCAVATOR ASN LC-2301 (11/88-12/03) (09-005) - BUCKET ASSY, RIPPER 0.7M Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
210 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1840F2 | [1] | BUCKET ASSY,RIPPER 0.7M3 | |
| 2. | 2412U173F1 | [2] | BUCKET TOOTH POINT | KOB |
| 2-1. | 2412U173S1 | [1] | POINT, TOOTH | POINT, TOOTH |
| 2-2. | 2412U62S2 | [1] | PIN | KOB |
| 2-3. | 2412U62S3 | [1] | LOCK PIN | KOB |
| 3. | 2412U25F1 | [1] | TOOTH | KOBTOOTH ASSY |
| 3-1. | 2412U25S1 | [1] | POINT | POINT |
| 3-2. | 2412U25S2 | [1] | PIN | |
| 3-3. | 2412U25S3 | [1] | RUBBER | |
| 4. | 2445Z1003 | [4] | O-RING | KOB |
| 5. | 2412J1271F1 | [2] | BUCKET,RIPPER | |
| 5-1. | 2412J1271 | [1] | BUCKET | |
| 5-1T. | 2412U24 | [1] | NOSE | |
| 5-1U. | 2412U187 | [2] | ADAPTER | KOB |
| 5-26. | 2405T911 | [4] | BUSHING | KOB |
| 6. | ZP26D04010 | [2] | ROLL PIN | KOB |
