纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-054[02]) - GUARD INSTAL (CANOPY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
686 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2-2. | PW22C01067P1 | [1] | LOCK | KOB |
| 2-3. | PH22C01023P1 | [4] | BOLT | KOB |
| 2-4. | ZN18C05004 | [4] | NUT | KOB |
| 2-5. | ZW26X05000 | [4] | LOCK WASHER | KOBLOCK |
| 2-6. | PM21C01268F1 | [1] | LOCK | KOB |
| 2-6A. | YR22C01025P2 | [1] | LOCK | KOB |
| 2-6B. | PM21C01269P1 | [1] | PLATE | KOB |
| 2-7. | ZW16H05000 | [4] | WASHER | KOB |
| 2-9. | PW22C01160P2 | [1] | BRACKET | KOB Superseded by part number: PW22C01160P3 |
| 3-1. | PW21C01657P1 | [1] | COVER | KOB(Primer Colored) |
| 3-2. | YZ21C01094D8 | [1] | WEATHERSTRIP | KOB |
| 3-3. | PM21C01152DR | [1] | WEATHERSTRIP | KOB |
| 3-4. | PM21C01091DK | [1] | WEATHERSTRIP | KOB |
| 3-5. | PW21C01718D1 | [1] | RUBBER | KOB |
| 3-6. | PE21C01135D3 | [1] | TRIM PANEL | KOB |
| 17. | ZW16X08000 | [2] | WASHER | KOB |
| 18. | 2419R9D2 | [1] | COTTER PIN | KOB |
| 19. | PA41C01005D3 | [2] | BOLT | KOB |
| 20. | YT21C01187P2 | [2] | WASHER | KOB |
| 21. | PA21C01133P1 | [2] | BOLT | KOB |
| 38. | PW22C01166P1 | [1] | STAY | KOBSTAY |
| 45. | PM21C01142P1 | [1] | BOLT | KOB |
