纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-054[03]) - GUARD INSTAL (CANOPY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
185 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | PW21C00027F1 | [1] | COVER ASSY | KOBCOVER ASSY, SIDE Superseded by part number: PW21C00023F1 |
| 1-1. | PW21C01667P1 | [1] | COVER | KOBCOVER |
| 1-1H. | PW21C01635P1 | [2] | HINGE | KOB |
| 1-2. | PW21C01799F1 | [1] | GUARD | KOBGUARD ASSY |
| 1-2A. | PW21C01784P1 | [1] | GUARD | KOBGUARD |
| 1-2C. | PW21C01583D2 | [1] | RUBBER | KOB |
| 1-2D. | PW21C01583D3 | [2] | RUBBER | KOB |
| 1-3. | ZN18C06005 | [6] | NUT | KOB |
| 1-4. | ZW26X06000 | [6] | LOCK WASHER | KOB |
| 1-5. | YT21P01001P1 | [6] | WASHER | KOB |
| 1-6. | YN21C01321P1 | [1] | STOP | KOB Superseded by part number: YN21C03212P1 |
| 1-7. | ZN17F10008 | [1] | NUT | KOB Superseded by part number: ZN18F10008 |
| 1-8. | PM21C01268F1 | [1] | LOCK | KOB |
| 1-8A. | YR22C01025P2 | [1] | LOCK | KOB |
| 1-8B. | PM21C01269P1 | [1] | PLATE | KOB |
| 1-9. | PW21C01636P1 | [1] | FOAM INSULATION | KOB |
| 1-10. | PW21C01682P1 | [2] | RUBBER | KOB |
| 1-11. | YW21C01057D1 | [1] | WEATHERSTRIP | KOB |
| 1-12. | PW21C01583D1 | [1] | RUBBER | KOB |
| 1-13. | PW21C01713P1 | [1] | GUARD | KOB |
| 1-14. | ZS41C05012 | [2] | CAPSCREW,M5 x 12mm | KOBSCREW MACHINE |
| 1-15. | PW21C01742P3 | [1] | RUBBER | KOB |
| 1-16. | PW21C01740P3 | [1] | RUBBER | KOB |
| 1-17. | PE21C01135D8 | [1] | SEAL | KOB |
| 4. | PW21C01801F1 | [1] | COVER ASSY | KOBCOVER ASSY |
| 4-1. | PW21C01802P1 | [1] | COVER ASSY | KOBR.H. Superseded by part number: PW21C01802P2 |
| 4-2. | PM21C01233P1 | [1] | RUBBER | KOB |
| 4-3. | 2427P1836D32 | [1] | WEATHERSTRIP | KOB |
| 4-4. | PW21C01629P1 | [1] | FOAM INSULATION | KOB |
| 19. | PA41C01005D3 | [1] | BOLT | KOB |
| 27. | ZW26X12000 | [2] | WASHER | KOB |
| 31. | ZN18C12010 | [2] | NUT | KOB |
| 32. | ZW16H12000 | [2] | WASHER | KOB |
| 47. | PW21C01756D1 | [1] | SHIM | KOBSHIM (1.2) |
| 48. | PW21C01756D2 | [1] | SHIM | KOBSHIM (2.3) |
