纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-054[04]) - GUARD INSTAL (CANOPY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
669 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 6-2. | YJ21C01079D2 | [1] | WEATHERSTRIP | KOB |
| 6-3. | YT21C01163D3 | [1] | WEATHERSTRIP | KOB |
| 6-4. | YT21C01163D7 | [1] | WEATHERSTRIP | KOB |
| 6-5. | YJ21C01079D7 | [1] | WEATHERSTRIP | KOB |
| 7. | PW21C01788P1 | [1] | SUPPORT | KOBSUPPORT |
| 8. | PW21C01653P1 | [1] | STAY | KOBSTAY |
| 9. | PW21C01652P1 | [1] | BRACKET | KOB |
| 10. | PW21C01669P1 | [1] | STAY | KOBSTAY |
| 11. | PW21C01797F1 | [1] | PLATE | KOBPLATE ASSY |
| 11-1. | PW21C01785P1 | [1] | PLATE | KOBPLATE |
| 11-2. | 2427P1836D28 | [1] | WEATHERSTRIP | KOB |
| 11-3. | PH21C01136DK | [1] | RUBBER WEATHERSTRIP | KOBSTRIP, WEATHER |
| 12. | PW21C01660F1 | [1] | GUARD ASSY. | KOB |
| 12-1. | PW21C01661P1 | [1] | GUARD | KOB |
| 12-2. | YT21C01037D1 | [1] | TRIM PANEL | KOB |
| 12-3. | YJ21C01146D1 | [1] | TRIM PANEL | KOB |
| 12-4. | YJ21C01146D5 | [1] | SOFT TRIM | KOB |
| 13. | PW21C01689P1 | [1] | STRIKER PLATE | KOB |
| 14. | PW21C01699D1 | [2] | SHIM | KOB |
| 17. | ZW16X08000 | [1] | WASHER | KOB |
| 18. | 2419R9D2 | [1] | COTTER PIN | KOB |
| 19. | PA41C01005D3 | [2] | BOLT | KOB |
| 20. | YT21C01187P2 | [2] | WASHER | KOB |
| 21. | PA21C01133P1 | [2] | BOLT | KOB |
| 22. | ZS18C12045 | [2] | SCREW,Hex, M12 x 45mm | KOBCAP |
| 23. | ZS18C16050 | [2] | SCREW,Hex, M16 x 50mm | KOBCAP |
| 24. | ZW26X16000 | [2] | WASHER | KOB |
| 25. | ZW16H16000 | [2] | WASHER | KOB |
| 26. | ZS18C12050 | [2] | SCREW,Hex, M12 x 50mm | KOBCAP |
| 27. | ZW26X12000 | [6] | WASHER | KOB |
| 28. | 2418T10357 | [6] | WASHER | KOB Superseded by part number: 2418T12345 |
| 29. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOBCAP |
| 30. | ZM22C08020 | [4] | BOLT | KOB |
| 41. | PW21C01741F1 | [1] | BOX | KOBASSY |
| 41-1. | PW21C01748P1 | [1] | BOX | KOB Superseded by part number: PW21C01741F1 |
| 41-2. | PW21C01729P2 | [1] | RUBBER | KOB |
| 49. | YR21C01159P1 | [2] | BOLT | KOB |
