纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-055[05]) - GUARD INSTAL (CAB) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
259 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 6. | PW22C01151F1 | [1] | DUCT | KOBASSY |
| 6-1. | PW22C01149P1 | [1] | DUCT | KOB |
| 6-6. | YT21C01037D2 | [1] | TRIM PANEL | KOB |
| 6-7. | PW22C01105D1 | [1] | RUBBER | KOB Superseded by part number: PW22C01105D5 |
| 6-8. | PW22C01105D2 | [2] | RUBBER | KOB Superseded by part number: PW22C01105D5 |
| 6-9. | PW22C01105D3 | [1] | RUBBER | KOB Superseded by part number: PW22C01105D5 |
| 6-10. | PW22C01154P1 | [1] | FOAM INSULATION | KOB |
| 6-11. | PW22C01142P1 | [1] | FOAM INSULATION | KOB |
| 6-12. | PW22C01139P1 | [1] | FOAM INSULATION | KOB |
| 6-13. | PW22C01140P1 | [1] | FOAM INSULATION | KOB |
| 6-14. | PW22C01141P1 | [1] | FOAM INSULATION | KOB |
| 15. | PW21C01688P1 | [1] | BRACKET | KOB |
| 16. | PM21C01371P1 | [1] | LOCK | KOB |
| 30. | ZM22C08020 | [2] | BOLT | KOB |
| 33. | ZS18C06020 | [2] | SCREW,Hex, M6 x 20mm | KOB |
| 34. | ZW16H06000 | [4] | WASHER | KOB |
| 35. | ZN18C06005 | [2] | NUT | KOB |
| 36. | ZW26X06000 | [2] | LOCK WASHER | KOB |
