神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (01-006) - TANK ASSY, HYDR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
562 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J7658F1 | [1] | TANK ASSY, HYDR | |
| 1. | 2427J1890 | [1] | TANK, HYDR | |
| 2. | 2446R161F3 | [1] | STRAINER, SUCTION | |
| 2-1. | 2446R161S1 | [1] | STRAINER ELEMENT | KOB |
| 2-2. | 2446R110S2 | [1] | HOLDER | KOB |
| 2-4. | ZN16C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 2-5. | 2446R110S6 | [1] | SPRING | KOB |
| 2-6. | 45Z91D7 | [1] | O-RING | KOB |
| 2-8. | 2446R161S8 | [1] | BOLT | BOLT |
| 3. | 2418T7763 | [2] | FLANGE | |
| 4. | 2418T13680 | [1] | FLANGE | |
| 5. | ZD11G22000 | [1] | O-RING,5.7mm Thk x 219.3mm ID, 70 Duro | KOBO-Ring -- ID 219.30 ± 1.68 x OD 222.66mm |
| 6. | ZD11G19000 | [2] | O-RING,189.30mm ID x 200.70mm OD x 5.70mm | KOBID 189.30 ± 1.47 x OD 200mm |
| 7. | 2436Z274D4 | [1] | VALVE PRESSURE RELIE | KOB |
| 8. | ZE72X12000 | [1] | PLUG | KOB(3/4" PF) (Incls. O-Ring ZD12P02400) |
| 9. | 2489R173F1 | [1] | PORTABLE LAMP | KOBGAUGE, LEVEL |
| 9-1. | 2489R173S1 | [1] | GAUGE | KOB |
| 9-2. | 2489R173S2 | [2] | BOLT | BOLT |
| 9-3. | 2489R173S3 | [2] | SHORT ENGINE | KOBSHORT ENGINE |
| 9-4. | ZD11P01800 | [1] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 9-5. | ZD11P01400 | [2] | O-RING | KOBID 13.8 ± 0.19 x OD 18.6mm |
| 10. | ZS18C16035 | [4] | SCREW,Hex, M16 x 35mm | KOBM16x2.0x35mm |
| 11. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 13. | ZM11C12030 | [8] | SCREW | KOBM12x1.75x30mm (Incls. Lockwasher) Superseded by part number: ZM12C12030 |
| 14. | R36P0002 | [2] | ELEMENT | KOB Superseded by part number: YN50V00001P1 |
| 15. | 2417T296 | [2] | SPRING | KOB |
| 16. | 2446R131 | [2] | VALVE | KOB |
| 17. | 2446U214F1 | [1] | HYDRAULIC OIL FILTER | KOBDRAIN |
| 17-3. | 2446U141S2 | [1] | SPARE PART | HITCARTRIDGE Superseded by part number: S15510-20200 |
| 18. | B16T0187D1 | [1] | SHIM, 1.6 | SHIM, 1.6 |
| 19. | B16T0187D2 | [1] | SHIM, 2.3 | SHIM, 2.3 |
| 20. | 2444Z2657 | [1] | TEE | TEE |
| 21. | ZM11C10020 | [2] | SCREW | KOBM10x1.50x20mm (Incls. Lockwasher) Superseded by part number: ZM12C10020 |
| 22. | 2418T5373C2 | [4] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 23. | ZM11C10025 | [8] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 24. | B16T0187D7 | [1] | SHIM | |
| 25. | B16T0187D8 | [1] | SHIM | |
| 26. | ZF33F28016 | [1] | ELBOW | KOB Superseded by part number: ZA33F28016 |
| 27. | 2416T12222 | [1] | BRACKET | |
| 28. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 28-1. | ZD12P02240 | [1] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 29. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
