纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-061) - ELEC ASSY, UPP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
711 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW03E00006F1 | [1] | ELEC ASSY, UPP | |
| A1. | PW24E00039F1 | [1] | RELAY | KOBASSY, SEE FIG 01-066 |
| A3. | PY53S00002P1 | [1] | HORN | KOB |
| A4. | PW13E01079D1 | [1] | CABLE | KOB |
| A5. | PW13E01044D1 | [1] | CABLE | KOB |
| A7. | PW13E01042P1 | [1] | GROMMET | KOB |
| A8. | PH13E01072P1 | [1] | GROMMET | KOB Superseded by part number: 72282258 |
| A9. | PW13E01076P1 | [1] | GROMMET | KOBGROMMET |
| A10. | PW13E01060P1 | [1] | GROMMET | KOB |
| A11. | EW02E01015D6 | [1] | CLIP | KOB |
| A12. | EW02E01015D8 | [2] | CLIP | KOB |
| A13. | YN03E01001D4 | [2] | CLIP,33mm L | KOB |
| A14. | YN03E01001D5 | [5] | CLIP | KOB |
| A16. | PY01P01043D5 | [24] | CABLE TIE,301mm L | KOB |
| A18. | ZM61C06020 | [2] | BOLT | KOB |
| A20. | ZS18C08014 | [3] | SCREW,Hex, M8 x 14mm | KOBCAP |
| A21. | ZS18C10016 | [2] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| A22. | ZW16X08000 | [5] | WASHER | KOB |
| A23. | ZW16X10000 | [4] | WASHER | KOB |
| A24. | ZW26X08000 | [5] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| A25. | ZW26X10000 | [4] | LOCK WASHER | KOB |
| A26. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| A27. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| A28. | ZM11C08016 | [1] | BOLT | KOB |
| A30. | PW14E01038D1 | [1] | HARNESS | KOB |
| B1. | PW03Z00013P1 | [1] | SCHEMATIC, ELEC | |
