纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (01-060) - HEATER ASSY (WITHOUT HEATER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
554 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW21M00012F1 | [1] | HEATER ASSY | |
| 1. | 2420Z1042 | [1] | GROMMET | KOB Superseded by part number: 2420Z1301 |
| 2. | PW17M01021P1 | [2] | CAP | KOB |
| 4. | PA03M01093D2 | [14] | BOLT | KOBSEMS-BOLT Superseded by part number: ZM27C08020 |
| 6. | PM22C01013DB | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 7. | 2420R429D4 | [2] | GROMMET | KOB |
| 9. | PW10M01267F1 | [1] | COVER ASSY | |
| 9-1. | PW21M01025P1 | [1] | SUPPORT | KOBCOVER Superseded by part number: PV21M01018P1 |
| 9-2. | PW10M01145P2 | [1] | FOAM INSULATION | KOBINSULATION |
