纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (02-007) - ROLLER ASSY, UPP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
790 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW64D00008F1 | [1] | ROLLER | AROLLER ASSY, UPP |
| 1. | PW64D01017F1 | [2] | ROLLER ASSY. | KOB |
| 1-1. | PW64D01018P1 | [1] | ROLLER | KOB |
| 1-2. | PW64D01019P1 | [1] | SHAFT | KOB |
| 1-3. | PV64D01001P1 | [1] | COVER | KOB |
| 1-4. | PW64D01020P1 | [1] | COVER | KOB |
| 1-5. | PU64D01004P1 | [2] | BEARING | KOB |
| 1-6. | 2445Z1503 | [1] | SEAL | KOB |
| 1-7. | ZR26X05200 | [1] | RING | KOB |
| 1-8. | ZD11G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 1-9. | PV52D01007P1 | [1] | PLUG | KOB |
| 2. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOBCAP |
| 3. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
