纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (02-006) - ROLLER ASSY, TRACK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
928 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX64D00010F1 | [1] | ROLLER ASSY, TRACK | |
| 1. | PX64D00009F1 | [8] | ROLLER ASSY.,107mm OD x 171mm W | KOBTRACK, LOW |
| 1-1. | PX64D01005P1 | [1] | ROLLER | KOB Superseded by part number: PX64D00009F1 |
| 1-4. | PX64D01008P1 | [1] | COLLAR | KOB |
| 1-5. | PX64D01009P1 | [1] | COLLAR | KOB |
| 1-6. | PX64D01010P1 | [1] | SHAFT | KOB |
| 1-7. | PX64D01011P1 | [2] | BUSHING | KOB |
| 1-8. | PX64D01012P1 | [1] | RING | KOBRETAINING |
| 1-9. | PX64D01013P1 | [2] | SEAL | KOBFLOATING Superseded by part number: 2445R360F1 |
| 1-10. | ZD11G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOB |
| 1-11. | ZE82T02000 | [1] | PLUG | KOB |
| 2. | PX64D01014P1 | [16] | CAPSCREW | KOBSCREW CAP |
| 3. | ZW16H14000 | [16] | WASHER | KOB |
