纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (03-002) - HYD LINES, BOOM, 2.5M (8FT 2 IN) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
817 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX42H00053F1 | [1] | HYD LINES, BOOM | |
| A1. | PX42H01058P1 | [2] | TUBE | KOBTUBE |
| A2. | PX42H01059P1 | [2] | TUBE | KOBTUBE |
| A3. | PM42H01063P1 | [2] | RUBBER | KOB |
| A4. | ZS18C08016 | [4] | SCREW,Hex, M8 x 16mm | KOBCAP |
| A5. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOB |
| A6. | ZS18C10040 | [8] | SCREW,Hex, M10 x 40mm | KOBCAP |
| A7. | ZW26X08000 | [4] | LOCK WASHER | KOB Superseded by part number: 83990583 |
| A8. | ZW26X10000 | [10] | LOCK WASHER | KOB |
| A9. | ZW16X10000 | [2] | WASHER | KOB |
| A10. | PX42H01166P1 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| . . | PX42H00028F1 | [1] | HYD LINES, BOOM | |
| B1. | PX42H01083P1 | [2] | CLAMP | KOB |
| B2. | PX42H01084P1 | [2] | CLAMP | KOB |
| B3. | PX42H01085P1 | [1] | PLATE | KOB |
| . . | PX42H00056F1 | [1] | HYD LINES, CYLINDER | |
| C1. | PW42H01104D8 | [1] | HOSE | KOB |
| C2. | PW42H01104DD | [1] | HOSE | |
| C3. | HH25S06006G1 | [2] | HYD CONNECTOR | KOB Superseded by part number: 124537A1 |
| C4. | ZC46X25011 | [1] | CLIP | KOB |
| C5. | PX42H01171P1 | [1] | BUSHING | KOB |
| C7. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| . . | PX42H00057F1 | [1] | HYD LINES, CYLINDER | |
| D1. | PW42H01104D7 | [1] | HOSE,9.5mm ID x 1420mm L | KOB |
| D2. | PX42H01170D2 | [1] | HYDRAULIC HOSE | KOB |
| D4. | ZC46X19011 | [1] | CLIP | KOB |
| D8. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOB |
| D9. | HH35S06006G1 | [1] | 90 ELBOW,90°, 3/8" PF x 3/8" PF x 60mm L | KOB |
