纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (03-001) - BOOM ASSY, STD 2.5M (8FT 2 IN) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
437 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX02B00142F1 | [1] | BOOM ASSY | |
| A1. | PX02B00143F1 | [1] | BOOM | KOBBOOM, HOE Superseded by part number: PX02B00178F1 |
| A1-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBOOM, HOE |
| A1-1Q. | PM02B01266P1 | [4] | BLOCK | KOB |
| A1-1R. | PW02B01260P1 | [2] | BLOCK | KOB |
| A1-1T. | PM02B01253P1 | [2] | BLOCK | KOB |
| A1-1U. | R16T0373D7 | [1] | BLOCK | KOB |
| A1-2. | PX02B01106P1 | [2] | BUSHING,45mm ID x 55mm OD x 55mm L | KOB |
| A1-3. | PW02B01215P1 | [1] | COLLAR | KOB |
| . . | PX02B00082F1 | [1] | BOOM INSTAL | |
| B1. | PX02B01238P1 | [1] | PIN,Dia=45mm, L=301mm | KOB |
| B2. | 2418T21137 | [1] | WASHER | KOB |
| B3. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| B4. | ZW26X10000 | [1] | LOCK WASHER | KOB |
| . . | PX02B00124F1 | [1] | BOOM GROUP | |
| C1. | PX02B01245P1 | [1] | COVER | KOB |
| C4. | ZW16H10000 | [1] | WASHER | KOB |
| C5. | PN03M01009D2 | [1] | WASHER | KOB |
| C6. | 2445R138D20 | [2] | SEAL,45mm ID x 55mm OD x 4mm Thk | KOBDUST |
| C7. | ZG91V02000 | [1] | LUBE NIPPLE | KOB |
| C8. | PX02B01244P1 | [2] | TUBE | KOB |
| C9. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
