卡特零件查询（730C） 390-5238: LINES GP-AIR CONDITIONER
广数供应链运营团队, 15 02月, 2025，浏览：
618 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 217-7742 | [1] | GROMMET | |
| 2. | 308-2583 | [1] | ACCUMULATOR-REFRIGERANT(CHARGED) | |
| 3. | 320-0562 | [1] | DRYER AS-REFRIGERANT(IN-LINE) | |
| | 189-1707 | [1] | ORIFICE AS-AIR CONDITIONER | |
| | 325-4416M | [2] | STUD(M8X1.25X52-MM) | |
| 4. | 327-0282 | [1] | SEAL-INTEGRAL(1/2-IN) | |
| 5. | 327-0283 | [1] | SEAL-INTEGRAL(3/4-IN) | |
| 6. | 348-5748 | [1] | HOSE AS | |
| 7. | 390-5239 | [1] | HOSE AS | |
| 8. | 109-1633 | [1] | CLIP(SLOT) | |
| 9. | 109-1634 | [1] | CLIP(TAB) | |
| 10. | 178-3336M | [4] | NUT-HEX FLANGE(M8X1.25-THD) | |
| 11. | 7X-7910 | [1] | CLIP(SLOT) | |
| 12. | 7X-7911 | [1] | CLIP(TAB) | |
| 13. | 8T-4121 | [2] | WASHER-HARD(11X21X2.5-MM THK) | |
| 14. | 8T-4136M | [1] | BOLT(M10X1.5X25-MM) | |
| 15. | 8T-4195M | [1] | BOLT(M10X1.5X30-MM) | |
| | M | | METRIC PART |
