纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (03-005) - CYLINDER INSTAL (CAB) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
854 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PX02B00145F1 | [1] | CYLINDER INSTAL | |
| A1. | PW02B01306P1 | [1] | PIN,45mm OD x 151mm L | KOB |
| A2. | PX02B01263P1 | [1] | PIN,45mm OD x 187mm L | KOBPIN |
| A3. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| A4. | ZW26X10000 | [1] | LOCK WASHER | KOB |
| A5. | 2418T21137 | [1] | WASHER | KOB |
| A6. | YJ12B01097P1 | [2] | SHIM,47mm ID x 70mm OD x 0.5mm Thk | KOB |
| A7. | PR02B01121D1 | [3] | SHIM,47mm ID x 70mm OD x 0.9mm Thk | KOB |
| A8. | PX01V00065F1 | [1] | HYDRAULIC CYLINDER,Double Acting, 45mm Rod, 535mm Stroke | KOBCYLINDER ASSY, BOOM |
| A9. | HS18C10085G2 | [1] | BOLT | KOBCAP |
| A10. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| . . | PW02B00141F1 | [1] | CYLINDER INSTAL | |
| B5. | PX01V00063F1 | [1] | CYLINDER | KOBCYLINDER ASSY, ARM Superseded by part number: PX01V00063F2 |
