神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (02-022) - CAT WALK ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1001 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J5585F1 | [1] | CATWALK ASSY(FOR NORTH AMERICA) | |
| 1. | 2422N714 | [1] | CATWALK | |
| 2. | 2422N715 | [1] | CATWALK | |
| 3. | 2422P878 | [1] | REWORK, FRAME | |
| 3-1. | 2416T6561 | [8] | BLOCK, TAPPED | BLOCK, TAPPED |
| 4. | 2416P4918 | [4] | BRACKET | BRACKET |
| 5. | 2416P4919 | [2] | BRACKET | BRACKET |
| 6. | ZS18C10025 | [16] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 7. | ZS18C16035 | [16] | SCREW,Hex, M16 x 35mm | KOBM16x2.0x35mm |
| 8. | ZN18C10008 | [16] | NUT | KOBM10x1.50mm |
| 9. | 2418T5373C2 | [16] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 10. | ZW26X16000 | [16] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 11. | 2416P4936 | [2] | BRACKET | BRACKET |
| 12. | 2422N1188 | [1] | CATWALK | |
| 13. | 2422N1189 | [1] | CATWALK | |
| 14. | ZW26X10000 | [16] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
