纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (05-005) - FUEL LINES (COOLER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
568 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW21P00008F1 | [1] | FUEL LINES | |
| 1. | PW02P01046P1 | [1] | SEPARATOR | KOBWATER Superseded by part number: VV11980255700 |
| 2. | PH21P01008D2 | [1] | HOSE | KOB |
| 3. | PH21P01003DL | [1] | HOSE | KOB Superseded by part number: PA21P01004DC |
| 4. | PA21P01004DJ | [1] | HOSE ASSY. | KOBHOSE Superseded by part number: PA21P01004D7 |
| 5. | PW21P01003DS | [2] | TUBE | KOB |
| 7. | PU13E01002D5 | [1] | TUBE | KOB |
| 8. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 9. | PH05P01088D5 | [6] | CLIP | KOB |
| 10. | PH05P01088D6 | [2] | CLIP | KOB |
| 11. | ZS18C08075 | [1] | SCREW,Hex, M8 x 75mm | KOBCAP |
| 12. | ZW16X08000 | [1] | WASHER | KOB |
| 13. | ZW26X08000 | [1] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 17. | PA21P01003D2 | [2] | CLIP | KOB |
| 18. | PU13E01002DK | [2] | TUBE | KOB |
| 19. | PW22P00001P1 | [1] | FUEL PUMP | KOB Superseded by part number: VV12961252100 |
| 20. | PA21P01004DS | [1] | HOSE | KOB Superseded by part number: PA21P01004D7 |
| 22. | ZW16X10000 | [2] | WASHER | KOB |
| 24. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBCAP |
| 25. | ZW16X06000 | [2] | WASHER | KOB Superseded by part number: 86588450 |
| 27. | HX11Y04050DX | [1] | HOSE,6mm ID x 500mm L | KOB Superseded by part number: 72280610 |
| 28. | PW21P01016P1 | [1] | BRACKET | KOBBRACKET |
| 29. | PW21P01018P1 | [1] | COVER | KOBCOVER |
| 30. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| 31. | PU13E01002D6 | [1] | TUBE | KOB Superseded by part number: 72280613 |
| 32. | PM21P01010P1 | [1] | HOSE ASSY. | KOB Superseded by part number: VV11984059601 |
