凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (18.87727122[01]) - DIA : KNIFE DRAWER KIT - KNIFE DRAWER FOR 33 KNIVES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
221 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
87727122
|
[1] |
DIA KIT, HARVESTER
|
ATT
|
| 1. |
87745279
|
[1] |
KNIFE HOLDER
|
ZED
|
| 2. |
86629499
|
[8] |
BALL BEARING,20mm ID x 42mm OD x 12mm W
|
ZED
|
| 3. |
84042244
|
[1] |
FIXING PLATE
|
ZED
|
| 4. |
84042245
|
[2] |
FIXING PLATE
|
ZED
|
| 5. |
84042270
|
[1] |
CANVAS
|
ZED
|
| 6. |
84041706
|
[8] |
ROLLER
|
ZED
|
| 7. |
87631919
|
[1] |
ROD
|
ZED
|
| 8. |
333960
|
[3] |
LOCK PIN,6mm OD x 50mm L, Slotted
|
NH
|
| 9. |
445395
|
[10] |
RIVET,Pop, 4.8mm OD x 18.1mm L
|
IH
|
| 10. |
84039310
|
[2] |
HEX PLUG,44mm L
|
ZED
|
| 11. |
140090
|
[1] |
WASHER
|
PA
|
| 12. |
9706687
|
[2] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 13. |
140109
|
[2] |
WASHER,31mm ID x 40mm OD x 2mm Thk
|
NH
|
| 14. |
84039459
|
[1] |
PIN,16mm OD
|
ZED
|
| 15. |
84043589
|
[1] |
SPRING
|
ZED
|
| 16. |
370024
|
[8] |
CIRCLIP,M20, Ext
|
NH
|
| 17. |
300645
|
[8] |
SNAP RING,M42, Int
|
NH
|
| 18. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
