凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (18.87727441[01]) - DIA : PARTIAL BALE EJECT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
458 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
87727441
|
[1] |
DIA KIT, HARVESTER
|
ATT
|
| 1. |
84122072
|
[1] |
CROSSRAIL
|
ZED
|
| 2. |
84160355
|
[1] |
LATH
|
ZED
|
| 3. |
84160359
|
[1] |
LATH
|
ZED
|
| 4. |
374895
|
[6] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 5. |
87491174
|
[1] |
SHAFT
|
ZED
|
| 6. |
87675257
|
[2] |
BRACKET
|
ZED
|
| 7. |
87675259
|
[1] |
SHAFT
|
ZED
|
| 8. |
84145759
|
[4] |
TOOTH
|
ZED
|
| 9. |
84122087
|
[4] |
SHIM
|
ZED
|
| 10. |
84122089
|
[4] |
SHIM
|
ZED
|
| 11. |
328754
|
[8] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 12. |
140046
|
[14] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 13. |
9706685
|
[14] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 14. |
378247
|
[4] |
WASHER,21mm ID x 39mm OD x 3mm Thk
|
ZED
|
| 15. |
370024
|
[4] |
CIRCLIP,M20, Ext
|
NH
|
| 16. |
87675249
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 35mm Rod, 470mm Stroke
|
ZED
|
| 17. |
87492701
|
[2] |
FLEXIBLE HOSE
|
ZED
|
| 18. |
87475047
|
[1] |
HYDRAULIC VALVE
|
ZED
Superseded by part number: 84568220
|
| 19. |
87479616
|
[1] |
DECAL
|
ZED
|
| 20. |
84449514
|
[1] |
HYD CONNECTOR
|
ZED
|
