凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (18.87727122[03]) - DIA : KNIFE DRAWER KIT - KNIFE DRAWER FOR 33 KNIVES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
782 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
87727122
|
[1] |
DIA KIT, HARVESTER
|
ATT
|
| 1. |
84461532
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 25mm Rod, 120mm Stroke
|
ZED
|
| 2. |
9501786
|
[1] |
PIN,20mm OD x 100mm L
|
LEC
|
| 3. |
378247
|
[7] |
WASHER,21mm ID x 39mm OD x 3mm Thk
|
ZED
|
| 4. |
412686
|
[1] |
COTTER PIN,M5 x 32
|
NH
|
| 5. |
9839372
|
[2] |
CLAMP,11.1mm, Coat, 10.3mm Bolt Hole, P Type
|
ZED
|
| 6. |
84058832
|
[1] |
CLIP
|
ZED
|
| 7. |
9512290
|
[2] |
RIVET,Pop, 4.8mm OD x 17.8mm L
|
ZED
|
| 8. |
87680717
|
[1] |
SENSOR
|
ZED
B10 - STATUS CUTTER Superseded by part number: 84391774
|
| 9. |
84037257
|
[2] |
HYD CONNECTOR
|
ZED
|
| 10. |
86566990
|
[4] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
CABLE STRAP
|
| . . |
87369262
|
[1] |
|
|
