纽荷兰零件查询(E35SR) - COMPACT CRAWLER EXCAVATOR ASN PX13-15001 (N6TN61732) (NA) (1/06-) (05-016) - COOLER ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
237 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW20M00028F1 | [1] | COOLER ASSY. | KOBCOOLER ASSY |
| A1. | ZW16P08000 | [9] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| A2. | ZW26X08000 | [3] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| A3. | ZS18C08050 | [1] | SCREW,Hex, M8 x 50mm | KOBCAP |
| A4. | PH20M01035P2 | [1] | PULLEY | KOB |
| A5. | ZW16H10000 | [2] | WASHER | KOB |
| A6. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOB |
| A7. | ZW26X10000 | [4] | LOCK WASHER | KOB |
| A8. | ZS18C10030 | [7] | SCREW,Hex, M10 x 30mm | KOBCAP |
| A9. | ZC45X14011 | [2] | CLIP | KOBCLIP |
| A10. | ZM22C08020 | [12] | BOLT | KOB |
| A11. | PW20M01210P1 | [1] | PLATE | KOBPLATE |
| A12. | PW20M01214P1 | [1] | GASKET | KOBRUBBER |
| A13. | PW20M01213P1 | [1] | PLATE | KOBPLATE |
| A14. | ZS18C08100 | [1] | SCREW,Hex, M8 x 100mm | KOBSCREW |
| A15. | ZC48X24014 | [1] | CLIP | KOBClamp, Double -- Ø24x85mm Long |
| A16. | YY22P01010D4 | [1] | SOFT TRIM | KOBTRIM |
| A17. | PW20M01195P1 | [1] | COVER | KOBCOVER Superseded by part number: PW20M01226P2 |
| A18. | PM22C01013DJ | [2] | WEATHERSTRIP | KOB |
| A19. | PA03M01093D2 | [2] | BOLT | KOB Superseded by part number: ZM27C08020 |
| A21. | PE03H01005P1 | [1] | GROMMET | KOBGROMMET |
| A22. | ZM22C10025 | [4] | BOLT | KOB |
| A23. | PA03M01093D5 | [2] | BOLT | KOBSEMS-BOLT Superseded by part number: ZM27C08030 |
| A24. | ZW16P10000 | [1] | WASHER | KOBID 05 x OD 10 x Th 2.0mm |
| A25. | PW20M01190P2 | [1] | BRACKET | KOBBRACKET Superseded by part number: PW20M01190P3 |
| A26. | PH20M01129F1 | [1] | COVER | SMCOVER ASSY |
| A26-1. | PH20M01127P1 | [1] | COVER | KOBCOVER |
| A26-2. | PM02C01035D5 | [1] | STRIP | KOBSTRIP WEATHER |
| A26-3. | PM02C01035D7 | [1] | STRIP | KOBSTRIP WEATHER |
| A26-4. | PM02C01035D8 | [1] | STRIP | KOBSTRIP WEATHER |
| A27. | PW20M01209P1 | [2] | DUCT | KOBDUCT |
| A28. | PW20M01219P1 | [1] | BRACKET | KOB |
| A29. | PW20M01149P1 | [1] | GROMMET | KOBGROMMET |
| A30. | PW20M01088P1 | [1] | PLATE | KOBPLATE |
| A31. | PW20M01155P1 | [1] | SCREW | KOBCAPSCREW |
| A32. | PW20M01097D1 | [1] | BELT | KOB |
| A33. | YN20M01356P1 | [2] | DIFFUSER | KOBGrille |
| A34. | ZM22C08016 | [4] | BOLT | KOB |
| A35. | YY22P01010D5 | [1] | SOFT TRIM | KOBTRIM |
| A36. | PY01P01043D6 | [5] | CABLE TIE,4.80mm W x 383mm L | KOB |
| A37. | ZM61C06020 | [2] | BOLT | KOB |
| A38. | PM03M01471D2 | [5] | CAPSCREW,BHD, M8 | KOBSCREW CAP |
| A39. | ZC16X01400 | [5] | CLIP | KOB |
| A40. | PU13E01010D3 | [1] | RIGID TUBE | KOB |
| A41. | PU13E01010DR | [1] | PIPE | KOBTUBE |
| A42. | PH20T01101P1 | [1] | LABEL | KOBLABEL |
| A43. | ZS18C06025 | [2] | SCREW,Hex, M6 x 25mm | KOBCAP |
| A44. | ZS18C08025 | [1] | SCREW,Hex, M8 x 25mm | KOBCAP |
| A45. | ZS18C08035 | [1] | SCREW,Hex, M8 x 35mm | KOBCAP |
| A46. | ZW16P06000 | [2] | WASHER | KOB |
| A48. | YN20M01046DA | [1] | PIPE | KOBTUBE |
| . . | PW20M00027F1 | [1] | CONDITIONER INSTAL | |
| B1. | PW20M01218P1 | [1] | COVER | KOBCOVER Superseded by part number: PW20M01222P1 |
