凯斯零件查询(LB433S) - BIG RECTANGULAR BALER (9/08-12/12) (00.00LB028[01]) - MAINTENANCE PARTS, PICK-UP MAIN DRIVE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
663 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
165590
|
[2] |
CONNECTING LINK
|
PA
Superseded by part number: 241-1316
|
| 2. |
86595275
|
[1] |
OFFSET LINK
|
ZED
Superseded by part number: 241-1716
|
| 3. |
80025817
|
[1] |
OFFSET LINK
|
ZED
Superseded by part number: 241-1716
|
| 4. |
552945
|
[2] |
BEARING ASSY,40 mm ID x 80 mm OD x 30.2 mm
|
NH
Superseded by part number: 412441
|
| 5. |
9837879
|
[1] |
CHAIN,Roller, 68 Links x 19.05mm = 1295.4mm
|
ZED
(1)
|
| 6. |
87517107
|
[3] |
DRIVEN SPROCKET
|
ZED
|
| 7. |
9837966
|
[1] |
CHAIN,Roller, 105 Links x 19.05mm = 2000.25mm
|
ZED
(1, 3)
|
| 8. |
9837842
|
[2] |
BEARING,35mm ID x 72mm OD x 19mm W
|
ZED
|
| 9. |
87517105
|
[2] |
DRIVEN SPROCKET
|
ZED
|
| 10. |
9837965
|
[1] |
CHAIN,Roller, 123 Links x 15.88mm = 1952.63mm
|
ZED
(11, 12)
|
| 11. |
25816
|
[1] |
OFFSET LINK
|
GI
Superseded by part number: 86595276
|
| 12. |
25194
|
[1] |
CONNECTING LINK
|
GI
Superseded by part number: 86537460
|
| 13. |
322360
|
[2] |
BALL BEARING,35mm ID x 72mm OD x 19mm W
|
ZED
|
| 14. |
87731708
|
[4] |
DISC
|
ZED
Clutch, Serial Range: -C869 Superseded by part number: 87565196
|
| 14. |
87565196
|
[4] |
DISC
|
BEL
Clutch, Start Serial: D870
|
| 15. |
84004498
|
[1] |
REPAIR KIT
|
ZED
Pawl, Contains 3 pawl & 3 spring
|
