神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (04-002) - HYDR LINES, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
229 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X1667F3 | [1] | HYDR LINES,UPP | |
| 3. | 2418P10538 | [1] | TUBE | TUBE |
| 5. | 2418N2142 | [1] | TUBE | TUBE |
| 6. | 2418P10539 | [1] | TUBE | TUBE |
| 7. | 2416T11556D1 | [1] | BRACKET | |
| 8. | 2416T11556D2 | [1] | BRACKET | |
| 9. | 2432T1212 | [4] | CLAMP | KOB |
| 10. | 2444T1342 | [2] | HYD CONNECTOR | KOB |
| 11. | ZE13X20001 | [8] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) Superseded by part number: ZE13X20000 |
| 12. | ZD12P03800 | [4] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 13. | ZD12P02900 | [2] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 14. | ZS23C14045 | [16] | SCREW,Hex Socket Head, M14 x 45mm | KOBM14x2.0x45mm Superseded by part number: ZS28C14045 |
| 15. | ZS18C12070 | [4] | SCREW,Hex, M12 x 70mm | KOBM12x1.75x70mm |
| 16. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 17. | ZW22K14000 | [16] | LOCK WASHER | KOBID 14.2 x OD 21.8 x Th 3.5mm |
| 16. | ZW16H12000 | [12] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 19. | ZN16C12010 | [8] | NUT | KOB Superseded by part number: ZN18C12010 |
| 20. | 2418N2675 | [1] | TUBE | TUBE |
| 21. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 22. | 2418N2701 | [1] | TUBE | TUBE |
| 23. | 2418T14455 | [1] | TUBE | KOB |
| 24. | ZF33F28012 | [1] | ELBOW | KOB Superseded by part number: ZA33F28012 |
| 25. | 2444Z2125 | [2] | CONNECTOR | CONNECTOR |
| 26. | 2416N4008 | [1] | BRACKET | |
| 27. | 2436R1123F1 | [1] | VALVE, CHECK CONTROL | VALVE, CHECK CONTROL |
| 28. | 2436U1795F1 | [1] | VALVE, CONTROL | VALVE, CONTROL |
| 29. | ZS18C10045 | [4] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 30. | ZS18C10085 | [2] | SCREW,Hex, M10 x 85mm | KOBM10x1.50x85mm |
| 31. | ZW26X10000 | [6] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 32. | ZN18C10008 | [6] | NUT | KOBM10x1.50mm |
| 33. | 2444Z2689D2 | [1] | HOSE | HOSE |
| 34. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 34-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 35. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 36. | 2445Z1073 | [2] | O-RING | |
| 37. | 2418N2723 | [1] | TUBE | TUBE |
