神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (04-003) - HYDR LINES, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
904 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X2015F3 | [1] | HYDR LINES, UPP | |
| 1. | 2418P11395 | [2] | TUBE | KOBTUBE |
| 2. | 2418P11396 | [2] | TUBE | KOB |
| 4. | 2418P10545 | [1] | TUBE | TUBE |
| 5. | 2418P11399D1 | [1] | TUBE | TUBE |
| 6. | 2418P11399D2 | [1] | TUBE | KOB |
| 7. | 2418P11399D3 | [1] | TUBE | KOB |
| 6. | 2418P11399D4 | [1] | TUBE | KOB |
| 9. | ZX28N12120 | [4] | HOSE | HOSE |
| 10. | ZX28S12076 | [1] | FLEXIBLE HOSE | KOB |
| 13. | R18P0168D14 | [1] | HOSE \u00d825.4x700mm Long | HOSE Ø25.4x700mm Long |
| 14. | 2416T16865 | [1] | BRACKET | |
| 15. | 2416T14726 | [2] | BRACKET | |
| 16. | R16P0035D9 | [1] | CLAMP | KOB |
| 17. | 2432T1196 | [2] | CLAMP | CLAMP |
| 16. | ZC15X03300 | [4] | CLIP | KOB |
| 19. | ZE13X12000 | [2] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 20. | 2444T1368 | [4] | HYD CONNECTOR | KOB Superseded by part number: 2444R690D19 |
| 21. | ZF23F28012 | [1] | HYD CONNECTOR | KOB |
| 27. | ZD12P02600 | [1] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 28. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 29. | ZD12P02900 | [8] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 30. | ZS23C10035 | [4] | SCREW,Hex Socket Head, M10 x 35mm | KOBM10x1.50x35mm |
| 31. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 32. | ZS18C12070 | [2] | SCREW,Hex, M12 x 70mm | KOBM12x1.75x70mm |
| 33. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 34. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 35. | 2418T5373C2 | [5] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 36. | ZW16H12000 | [6] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 37. | ZW22K10000 | [4] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 38. | ZN18C10008 | [3] | NUT | KOBM10x1.50mm |
| 39. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm |
| 42. | ZC45X25011 | [2] | CLIP Clamp -- ID 25mm Single Cable | CLIP Clamp -- ID 25mm Single Cable |
| 43. | 2418T14346 | [1] | TUBE | TUBE |
| 44. | 2420R745D1 | [1] | HOSE | HOSE |
| 45. | 2420R745D2 | [1] | HOSE | HOSE |
| 46. | 2444Z2680 | [1] | HYD CONNECTOR | KOB |
| 47. | ZH52X08000 | [1] | TEE,30 Degree Fl, Male, PF 1/2" x 1/2" x 1/2", O-Ring | KOB(Incls. O-Ring 237-6008) |
| 46. | 2418P14749 | [1] | TUBE | TUBE |
| 49. | 2418T14484 | [1] | TUBE | KOB |
| 49-2. | ZF93N28000 | [2] | TUBE NUT | KOB Superseded by part number: ZA93N28000 |
| 49-3. | ZF93S28000 | [2] | FERRULE | KOBSLEEVE Superseded by part number: ZA93S28000 |
| 50. | ZF53B28000 | [1] | TEE | TEE |
| 51. | ZC45X31014 | [1] | CLIP | KOBClamp -- ID 31mm Single Cable |
