| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | PW96V00005F1 | [1] | DRIER ASSY, AIR | |
| 1. | PW20M01198F1 | [1] | A/C HOSE | KOBTUBE ASSY |
| 1-2. | 2445Z1604D5 | [1] | O-RING | KOB |
| 2. | PW20M01197F1 | [1] | TUBE ASSY. | KOBTUBE ASSY |
| 3. | PH20M01118F1 | [1] | HOSE ASSY. | KOBHOSE ASSY |
| 3-2. | 2445Z1604D6 | [2] | O-RING | KOB |
| 4. | PH20M01121F1 | [1] | TUBE | KOBTUBE ASSY Superseded by part number: PW20M01241F1 |
| 5. | PW20M01203F1 | [1] | HOSE ASSY. | KOBHOSE ASSY |
| 6. | PW20M01201F1 | [1] | TUBE | KOBASSY |
| 6-2. | 2445Z1604D4 | [1] | O-RING | KOB |
| 7. | PW20M01071F1 | [1] | RECEIVER-DRIER,Air Conditioner | KOBRECEIVER |
| 8. | PW20M01072P1 | [1] | BRACKET | KOBBRACKET |
| 9. | PW20M01202F1 | [1] | TUBE ASSY. | KOBTUBE ASSY |
| 10. | PW20M01200F1 | [1] | HOSE ASSY. | KOBHOSE ASSY |
| 11. | PW20M01199F1 | [1] | HOSE ASSY. | KOBHOSE ASSY |
