神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (04-004) - HYDR LINES, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
235 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J7963F1 | [1] | HYDR LINES,UPP | |
| 1. | 2415U191F1 | [1] | BRACKET,PARKING | |
| 2. | 2418T14610 | [1] | TUBE | TUBE |
| 3. | ZF33F28012 | [1] | ELBOW | KOB Superseded by part number: ZA33F28012 |
| 4. | 2420R349D180 | [1] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 5. | 2420R349D1 | [1] | HOSE ASSY | HOSE ASSY |
| 6. | ZX15K08070 | [1] | FLEXIBLE HOSE | KOBN2 |
| 7. | ZX15K08025 | [1] | KIT | KOB |
| 8. | 2422T429 | [1] | PLATE | |
| 9. | 2436U969D3F1 | [1] | VALVE, SOLENOID | |
| 10. | ZH22X04000 | [3] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 11. | 2436R1062D21 | [1] | VALVE CHECK | |
| 12. | ZH31M08006 | [1] | ELBOW | KOB |
| 13. | ZH31M08006 | [1] | ELBOW | KOB |
| 14. | ZH21M08004 | [1] | HYD CONNECTOR | KOB |
| 15. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 15-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 16. | ZS23C06025 | [2] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 17. | ZN18C06005 | [2] | NUT | KOBM06x1.0mm |
| 18. | ZW22K06000 | [2] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 19. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 20. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 21. | 2479Z855 | [1] | SWITCH | KOB |
| 22. | 2432T1779 | [1] | STICKER | |
| 23. | 2418R312D1 | [1] | PLATE | KOB |
| 24. | 2414N2977 | [1] | COVER | |
| 25. | 2444T3202 | [1] | HYD CONNECTOR | KOB |
| 27. | 2444P1098D1 | [1] | HYD CONNECTOR | KOB3/8" PF x 50mm Long (Incls. O-Ring ZD12P01400) |
| 28. | 2444T3203 | [1] | TEE | |
| 29. | ZH51M08006 | [1] | TEE | KOB |
| 30. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 31. | 2420R745D3 | [1] | HOSE | KOB |
| 32. | 2444T3208 | [1] | TEE | TEE |
