神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (06-001) - POWER PLANT ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
197 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X2093F1 | [1] | POWER-PLANT ASSY | |
| 2. | 24100J3962F6 | [1] | PUMP ASSY,CONNECT SEE FIG 06-001 | |
| 3. | 2452U287F1 | [1] | RADIATOR SEE FIG 06-007 | RADIATOR SEE FIG 06-007 |
| 4. | 2446U128F3 | [1] | CLEANER AIR | |
| 4-13. | 2446U128S4 | [2] | BAND ASSY | BAND ASSY |
| 4-14. | 2446U162F1 | [1] | CLEANER, AIR | |
| 4-14A. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 4-14B. | 2446Z147S4 | [1] | AIR FILTER | HITELEMENT, INNER Superseded by part number: 87682968 |
| 4-14C. | 2446U128S2 | [1] | AIR CLEANER | KOB Superseded by part number: 87682983 |
| 4-14D. | 2446Z147S5 | [2] | NUT | KOBASSY |
| 4-14E. | NSS | [1] | NOT SOLD SEPARAT | CONBUFFLE ASSY |
| 4-14F. | NSS | [1] | NOT SOLD SEPARAT | CONCUP ASSY |
| 4-14G. | NSS | [1] | NOT SOLD SEPARAT | CONCLAMP ASSY |
| 4-14H. | NSS | [1] | NOT SOLD SEPARAT | CONO-RING |
| 5. | 2418T11151 | [4] | PLATE | |
| 6. | 2427U407F1 | [1] | CONTAINER | KOB |
| 6-1. | 2427U407S1 | [1] | CONTAINER | KOB |
| 6-2. | 2427U407S2 | [1] | CAP | KOB |
| 6-3. | 2427U407S3 | [1] | CAP | KOB |
| 6-4. | 2427U203S5 | [1] | SWITCH | KOB |
| 6-5. | 2427U203S3 | [1] | LABEL | KOB |
| 7. | 24100J3961F2 | [1] | MTG/ ENGINE SEE FIG 06-006 | |
| 8. | 2418N2664 | [1] | PIPE | PIPE |
| 9. | 2418P11710 | [1] | PIPE | PIPE |
| 10. | 2416P10081 | [1] | BRACKET | |
| 11. | 2416P10090 | [1] | BRACKET | |
| 12. | 2418P10574 | [1] | PIPE | PIPE |
| 13. | 2444R777 | [1] | FLEXIBLE HOSE | KOB |
| 14. | 244421600D7 | [1] | ELBOW, 90 | |
| 15. | 2420P1976 | [1] | FLEXIBLE HOSE | KOB |
| 16. | 2416P10758 | [1] | STAY | |
| 17. | 2416P9640 | [1] | STAY | |
| 18. | 2414N2883 | [1] | GUARD,FAN | |
| 19. | 2416P10347 | [1] | BRACKET | |
| 20. | 2479R686F2 | [1] | INDICATOR | INDICATOR |
| 20-3. | 2450U5D13 | [1] | INDICATOR, TURN SIGN | KOB |
| 21. | 2420T5384D1 | [2] | SHIM | |
| 22. | 2420T5384D2 | [2] | SHIM | |
| 23. | 2432T2007 | [1] | CLAMP | KOB |
| 24. | 2416T15464 | [1] | SUPPORT | |
| 25. | 2420T5383 | [1] | FLEXIBLE HOSE | KOB |
| 26. | 2432Z163D5 | [5] | CLAMP | KOBHOSE |
| 27. | 2420T3483 | [1] | GROMMET | KOB |
| 28. | 24322163D4 | [1] | CLAMP | |
| 29. | 2444Z1293D10 | [1] | LUBE NIPPLE | KOBNipple, Hose -- 3/8" PTx46mm Long |
| 30. | 2420Z795D2 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 77254532, HX11Y07100DX |
| 31. | 4018Z1022 | [2] | TUBE | |
| 33. | 2420Z912D1 | [1] | HOSE | KOB |
| 34. | ZC15X01000 | [5] | CLIP | KOB |
| 35. | ZC15X01300 | [3] | CLIP | KOB |
| 36. | ZC15X07000 | [4] | CLIP | KOB |
| 37. | ZC15X08000 | [4] | CLIP | KOB |
| 38. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 39. | ZG41B06000 | [1] | ELBOW | KOB |
| 42. | ZS18C12035 | [3] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 43. | ZS18C12040 | [1] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| 44. | ZS18F10030 | [3] | BOLT,Hex, M10 x 30mm | KOBM10x1.25x30mm |
| 45. | 2418R146D4 | [1] | HOSE | KOB |
| 46. | ZS18C10025 | [20] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 47. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 48. | ZS18C12050 | [4] | SCREW,Hex, M12 x 50mm | KOBM12x1.75x50mm |
| 50. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| 51. | ZN18C10008 | [3] | NUT | KOBM10x1.50mm |
| 52. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 53. | 2418T5373C2 | [13] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 54. | ZW16H12000 | [4] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 55. | ZW26X10000 | [24] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 56. | ZW26X12000 | [5] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 57. | 2418T13742 | [1] | PIPE | KOB |
| 58. | 2444R1391 | [1] | HOSE | KOB |
| 59. | ZC45X14011 | [1] | CLIP | KOBCLIP |
| 60. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 61. | ZS18C12025 | [1] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 32. | VA3113303800 | [1] | O-RING | KOBMITSUBISHI ENGINE PARTS |
