神钢零件查询(K912A) - EXCAVATOR BTW LC-2003 - LC-2016 (1/85-12/03) (06-002) - POWER PLANT ASSY (FOR NORTH AMERICA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
726 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X2093F2 | [1] | POWER-PLANT ASSY(FOR NORTH AMERICA) | |
| 2. | 24100J3962F6 | [1] | PUMP ASSY,CONNECTSEE FIG 06-003 | |
| 3. | 2452U2E7F1 | [1] | RADIATOR SEE FIG 06-007 | |
| 5. | 2418T11151 | [4] | PLATE | |
| 6. | 2427U407F1 | [1] | CONTAINER | KOB |
| 6-1. | 2427U407S1 | [1] | CONTAINER | KOB |
| 6-2. | 2427U407S2 | [1] | CAP | KOB |
| 6-3. | 2427U407S3 | [1] | CAP | KOB |
| 6-4. | 2427U203S5 | [1] | SWITCH | KOB |
| 6-5. | 2427U203S3 | [1] | LABEL | KOB |
| 7. | 24100J3961F2 | [1] | MTG,ENGINE SEE FIG 06-006 | |
| 11. | 2416P10081 | [1] | BRACKET | |
| 12. | 2418P10574 | [1] | PIPE | PIPE |
| 15. | 2420P1976 | [1] | FLEXIBLE HOSE | KOB |
| 16. | 2416P10758 | [1] | STAY | |
| 17. | 2416P9640 | [1] | STAY | |
| 18. | 2414N2883 | [1] | GUARD' FAN | |
| 19. | 2416P10089 | [1] | BRACKET | |
| 20. | 2479R686F2 | [1] | INDICATOR | INDICATOR |
| 20-3. | 2450U5D13 | [1] | INDICATOR, TURN SIGN | KOB |
| 21. | 2420T5384D1 | [2] | SHIM | |
| 22. | 2420T5384D2 | [2] | SHIM | |
| 23. | 2432T2007 | [1] | CLAMP | KOB |
| 24. | 2416T15464 | [1] | SUPPORT | |
| 25. | 2420T5383 | [1] | FLEXIBLE HOSE | KOB |
| 27. | 2420T3483 | [1] | GROMMET | KOB |
| 29. | 2444Z1293D10 | [1] | LUBE NIPPLE | KOBNipple, Hose -- 3/8" PTx46mm Long |
| 30. | 2420Z795D2 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 77254532, HX11Y07100DX |
| 31. | 4018Z1D22 | [2] | RIGID TUBE | KOB |
| 33. | 2420Z912D1 | [1] | HOSE | KOB |
| 34. | ZC15X01000 | [5] | CLIP | KOB |
| 35. | ZC15X01300 | [3] | CLIP | KOB |
| 36. | ZC15X07000 | [4] | CLIP | KOB |
| 37. | ZC15X08000 | [4] | CLIP | KOB |
| 38. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 39. | ZG41B06000 | [1] | ELBOW | KOB |
| 42. | ZS18C12035 | [3] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 43. | ZS18C12040 | [1] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| 44. | ZS18F10030 | [3] | BOLT,Hex, M10 x 30mm | KOBM10x1.25x30mm |
| 45. | 2418R146D4 | [1] | HOSE | KOB |
| 46. | ZS18C10025 | [12] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 47. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 48. | ZS18C12050 | [4] | SCREW,Hex, M12 x 50mm | KOBM12x1.75x50mm |
| 50. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| 51. | ZN18C12010 | [3] | NUT | KOBM12x1.75mm |
| 52. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 53. | 2418T5373C2 | [11] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 54. | ZW16H12000 | [4] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 55. | ZW26X10000 | [16] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 56. | ZW26X12000 | [5] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 59. | ZC45X14011 | [1] | CLIP | KOBCLIP |
| 60. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 61. | ZS16C12025 | [1] | CAPSCREW M12x1.75x25mm | CAPSCREW M12x1.75x25mm |
| 62. | 2416N3967 | [1] | BRACKET | BRACKET |
| 63. | 2432P1144 | [1] | BAND | KOB |
| 64. | 2446U167 | [1] | CAP, RAIN | CAP, RAIN |
| 65. | 2446U191F2 | [1] | AIR CLEANER | KOB |
| 65-1. | 2446U191S1 | [1] | BODY | BODY |
| 65-2. | 2446U191S2 | [1] | ELEMENT | KOBINNER Superseded by part number: 76615408 |
| 65-3. | 2446U191S3 | [1] | ELEMENT | HIT Superseded by part number: 84539219 |
| 65-<. | 2446Z147S5 | [1] | NUT | KOBASSY |
| 65-5. | 2446U191S5 | [1] | NUT | KOB |
| 65-6. | 2446U191S6 | [1] | COVER | KOB |
| 65-7. | 2446U191S7 | [1] | NUT | KOB |
| 65-8. | 2446U191S8 | [1] | CLIP | KOB |
| 65-9. | 2446U191S9 | [1] | GASKET | KOB |
| 65-10. | 2446U191S10 | [1] | VALVE | KOB Superseded by part number: 2446U162S11 |
| 66. | ZC15X13000 | [1] | CLIP | KOB |
| 67. | 2444Z1909 | [1] | REDUCER | KOB |
| 68. | ZC15X12500 | [3] | CLIP | KOB |
| 69. | 2444R738D3 | [1] | HOSE | KOB |
| 70. | 2418N2685 | [1] | PIPE N/A | PIPE N/A |
